WindSensor

curiouselectric·WindSensor·Wind Sensor PCB/WindSensorATMEGA328_PCB.kicad_pcb

WindSensor PCB layout, top view — open source AVR/Arduino board by curiouselectric

About the WindSensor PCB

WindSensor is an open source AVR/Arduino PCB design by curiouselectric, published on GitHub. It is a 2-layer board measuring 44.9 × 44.9 mm, with 42 components from 27 distinct parts.

Its main chip is the ATMEGA328P-AU, from the AVR/Arduino family. Other key parts include the TSV911XXLX. By type, the board carries 12 resistors, 11 capacitors, 9 connectors, 4 diodes, 3 ICs and 2 switches.

It belongs with the sensors designs in this gallery.

From the project

A DIY interface circuit for anemometers and wind vanes

This connects to various anemometers and wind vanes and provides a serial interface for averaged data from the pulses.

The problem with measuring wind anemometers and wind vane is that they constantly need to be checked. You need to know at all times when pulses have come in and which direction the wind vane is facing. This requires a bit of microcontroller time and processing. This unit is designed to solve that. Wire up your vane and anemometer. Power the unit up. Then it will save the averaged data for you. You can then get hold of the data through serial requests and process as you need.

WindSensor, from the project README
From the project README

Main components on the WindSensor

TSV911XXLXATMEGA328P-AU

WindSensor bill of materials (BOM)

42 components, 27 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
TSV911XXLX
TSV911xxLx
U1, U2
1
ATMEGA328P-AU
ATmega328P-AU
ATMEL
U4
1
8MHZ_XTAL
8MHz_XTAL
Y1
1
SERIAL
P2
1
ID
Valcon
P3
1
ISP
P4
1
LOGO2
P5
1
PCB
P6
1
VANE
P8
1
PROG
P9
1
I2C
P10
1
WIND_A
P11
1
C412368
SWA
SW1
1
C412368
RST
SW2
2
3V3_ZENER
3V3_Zener
D1, D4
1
LED0
D2
1
5V1_ZENER
5V1_Zener
D3
7
100N
100n
C1, C3, C4, C5, C7, C8, C11
1
22N
22n
C2
1
100U
100u
C6
Show 7 more
QtyPartRefs
2
22P
22p
C9, C10
4
10K
10k
R1, R5, R10, R11
4
4K7
4k7
R2, R3, R6, R7
1
470
R4
1
470K
470k
R8
1
100K
100k
R9
1
10k
R12

WindSensor design files

The KiCad project lives in the curiouselectric/WindSensor repository on GitHub; these links point at the commit this page was built from.

WindSensor: common questions

What microcontroller does the WindSensor use?

The WindSensor is built around the ATMEGA328P-AU, from the AVR/Arduino family.

How big is the WindSensor PCB?

The WindSensor measures 44.9 × 44.9 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the WindSensor?

42 components, from 27 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the WindSensor design files?

From the curiouselectric/WindSensor repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the WindSensor design in my own project?

The repository has no license, so all rights stay with curiouselectric. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the WindSensor without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
