Zigbee desk lamp

Czubixx·zigbee-desk-lamp·pcb/desk_lamp_cc2530.kicad_pcb

Zigbee desk lamp PCB layout, top view — open source board by Czubixx

About the Zigbee desk lamp PCB

Zigbee desk lamp is an open source PCB design by Czubixx, published on GitHub. It is a 2-layer board measuring 59.5 × 27 mm, with 18 components from 15 distinct parts.

Other key parts include the AMS1117-3.3, TTP223 and E18-MS1-PCB. By type, the board carries 5 capacitors, 5 resistors, 4 ICs and 4 transistors.

It belongs with the iot & wireless designs in this gallery.

From the project

DIY Zigbee desk lamp based on CC2530 controllable smart light for workbench/desk use.

Works with Zigbee2MQTT (Z2M). Supports groups and scenes. Supports On/Off, brightness control, Move, Stop, default move rate, and minimum/maximum brightness level. Smooth LED fade when turning on/off. Smooth brightness transitions. Works with any 12 V single-color PWM LED strip or LED module. Two built-in touch sensors: Tap to turn the light on or off. Touch and hold to adjust the brightness. Based on the low-cost CC2530 Zigbee microcontroller. No dedicated programmer is required to flash the firmware. Uses a standard microphone stand as a simple and inexpensive frame. * Can be built without…

Zigbee desk lamp, from the project README
From the project README

Main components on the Zigbee desk lamp

AMS1117-3.3TTP223E18-MS1-PCB

Zigbee desk lamp bill of materials (BOM)

18 components, 15 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
AMS1117-3.3
U1
2
TTP223
U2, U3
1
E18-MS1-PCB
U4
1
AOD4184
Q1
1
MMBT3906
Q2
2
MMBT3904
Q3, Q4
1
22UF
22uF
C1
1
10UF
10uF
C2
2
22pF (Opcional)
C3, C4
1
200PF
200pF
C6
1
2K7
2k7
R1
1
10R
R2
1
4K7
4k7
R3
1
200R
R4
1
100K
10k
R5

Zigbee desk lamp design files

The KiCad project lives in the Czubixx/zigbee-desk-lamp repository on GitHub; these links point at the commit this page was built from.

Zigbee desk lamp: common questions

How big is the Zigbee desk lamp PCB?

The Zigbee desk lamp measures 59.5 × 27 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Zigbee desk lamp?

18 components, from 15 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Zigbee desk lamp design files?

From the Czubixx/zigbee-desk-lamp repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Zigbee desk lamp design in my own project?

The repository has no license, so all rights stay with Czubixx. Use it as a reference, and ask the author before reusing the design.
