Micromouse-Board-Design

dancejjjjj·Micromouse-Board-Design·pcb/prototypeBoard micromouse.kicad_pcb

Micromouse-Board-Design layout, top view — open source ESP32 board by dancejjjjj
Simulate this board

About the Micromouse-Board-Design

Micromouse-Board-Design is an open source ESP32 PCB design by dancejjjjj, published on GitHub. It is a 2-layer board measuring 71.1 × 62.2 mm, with 8 components from 6 distinct parts.

Its main chip is the ESP32-S3-SuperMini, from the ESP32 family.

From the project

Hardware schematics and design files for an autonomous Micromouse robot based on the ESP32-S3 SuperMini.

Hardware schematics and design files for an autonomous Micromouse robot based on the ESP32-S3 SuperMini.

Google sheet link here: https://docs.google.com/spreadsheets/d/1piouLKvGbAHOj3b3Lox_jSpBq9OYytLLw8UId9fDQRM/edit?usp=sharing

Micromouse-Board-Design, from the project README
From the project README

Micromouse-Board-Design bill of materials (BOM)

8 components, 6 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
Conn_01x02_Pin
J1
1
~
ESP32-S3-SUPERMINI1
1
~
PCF1
1
~
TB6612FNG1
3
~
VL1, VL2, VL3
1
~
WeAct_Buck1

Micromouse-Board-Design design files

The KiCad project lives in the dancejjjjj/Micromouse-Board-Design repository on GitHub; these links point at the commit this page was built from.

Micromouse-Board-Design: common questions

What microcontroller does the Micromouse-Board-Design use?

The Micromouse-Board-Design is built around the ESP32-S3-SuperMini, from the ESP32 family.

How big is the Micromouse-Board-Design?

The Micromouse-Board-Design measures 71.1 × 62.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Micromouse-Board-Design?

8 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Micromouse-Board-Design design files?

From the dancejjjjj/Micromouse-Board-Design repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Micromouse-Board-Design design in my own project?

The repository has no license, so all rights stay with dancejjjjj. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Micromouse-Board-Design without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
