Misc file bin PCB layout, top view — open source AVR/Arduino board by GadgetReboot

About the Misc file bin PCB

Misc file bin is an open source AVR/Arduino PCB design by GadgetReboot, published on GitHub. It is a 2-layer board measuring 100 × 99.7 mm, with 38 components from 12 distinct parts.

Its main chip is the Arduino_Nano_Socket, from the AVR/Arduino family. Other key parts include the MCP23017_SP. By type, the board carries 15 jumpers, 7 capacitors, 5 ICs, 4 connectors, 4 resistors and 1 module.

From the project

Random files that don't belong anywhere in particular for one-off archiving

Misc file bin, from the project README
From the project README

Main components on the Misc file bin

MCP23017_SP

Misc file bin bill of materials (BOM)

38 components, 12 distinct parts.

QtyPartRefs
5
MCP23017_SP
U1, U2, U3, U4, U5
1
Arduino_Nano_Socket
M1
1
UART
J1
2
Conn_02x20_Odd_Even
J2, J3
1
Conn_01x04
J4
15
SolderJumper_3_Open
JP1, JP2, JP3, JP4, JP5, JP6, JP7, JP8 +7
1
SW_Push
SW2
1
LED_Small_ALT
D1
1
1uF
C1
6
100nF
C2, C3, C4, C5, C6, C7
3
10K
R1, R2, R4
1
680r
R3

Misc file bin design files

The KiCad project lives in the GadgetReboot/misc_file_bin repository on GitHub; these links point at the commit this page was built from.

Misc file bin: common questions

What microcontroller does the Misc file bin use?

The Misc file bin is built around the Arduino_Nano_Socket, from the AVR/Arduino family.

How big is the Misc file bin PCB?

The Misc file bin measures 100 × 99.7 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Misc file bin?

38 components, from 12 distinct parts. The full bill of materials is listed on this page.

Where can I download the Misc file bin design files?

From the GadgetReboot/misc_file_bin repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Misc file bin design in my own project?

The repository has no license, so all rights stay with GadgetReboot. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Misc file bin without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
