MotionModuleSTM32R8

griffotron·MotionModuleSTM32R8·PCB/MotionModuleSTM32F103R8/MotionModuleSTM32F103R8.kicad_pcb

MotionModuleSTM32R8 PCB layout, top view — open source STM32 board by griffotron

About the MotionModuleSTM32R8 PCB

MotionModuleSTM32R8 is an open source STM32 PCB design by griffotron, published on GitHub under the MIT license. It is a 4-layer board measuring 187.9 × 60.2 mm, with 240 components from 26 distinct parts.

Its main chip is the STM32F103R8T6, from the STM32 family. Other key parts include the AMS1117-3.3, MCP2562T-E/SN and TMC2209-LA-T. By type, the board carries 141 capacitors, 46 resistors, 31 connectors, 17 ICs, 3 diodes and 1 crystal.

It belongs with the robotics & motion designs in this gallery.

From the project

PCB design and code for the STM32 powered Motion Module that controls 14 stepper motors

The Motion Module uses an STM32F103R8 microcontroller to run 14 Trinamic TMC2209 stepper drivers. It recieves motor movement commands via CAN Bus from the ESP32 based Motion Controller. Please see the related repos for the ESP32 Controller and CAD Designs.

CAN Bus library is from https://github.com/pazi88/CANBus

MotionModuleSTM32R8, from the project README
From the project README

Main components on the MotionModuleSTM32R8

AMS1117-3.3MCP2562T-E/SNSTM32F103R8T6TMC2209-LA-T

MotionModuleSTM32R8 bill of materials (BOM)

240 components, 26 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
AMS1117-3.3
TWGMC
U1
1
MCP2562T-E/SN
MCP2562-E-SN
Microchip Tech
U2
1
STM32F103R8T6
STM32F103R8Tx
STMicroelectronics
U3
14
TMC2209-LA-T
TMC2209
TRINAMIC Motion Control GmbH
U4, U5, U6, U7, U8, U9, U10, U11 +6
1
X50328MSB2GI
Crystal
YXC Crystal Oscillators
Y1
2
SCREW_TERMINAL_01X02
Screw_Terminal_01x02
J1, J22
1
CONN_01X05_PIN
Conn_01x05_Pin
J2
14
B4B-PH-K-S(LF)(SN)
Conn_01x04_Pin
JST
J3, J5, J7, J9, J11, J13, J15, J17 +6
14
CONN_01X04_PIN
Conn_01x04_Pin
J4, J6, J8, J10, J12, J14, J16, J18 +6
1
PTS636SK25SMTRLFS
RESET
C&K
SW1
1
A-SP192YR6C-A02-4T
12v PWR LED
Amicc
D1
1
A-SP192GS1C-A01-4T
3.3v PWR LED
Amicc
D2
1
A-SP192DGHC-C01-4T
STATUS LED
Amicc
D3
65
CC0603KRX7R9BB104
0.1u 50V
YAGEO
C1, C5, C7, C8, C9, C10, C11, C12 +57
15
RST47UF25V035
47u
KNSCHA
C2, C128, C129, C130, C131, C132, C133, C134 +7
1
SPT1EM101E05TRVZC
100u
Yunxing
C3
1
FZ10UF25V90RV0144
10u
KNSCHA
C4
15
CL10A475KO8NNNC
4.7u 10v
Samsung Electro-Mechanics
C6, C22, C30, C38, C46, C54, C62, C70 +7
2
0603CG300J500NT
30pf
FH (Guangdong Fenghua Advanced Tech)
C14, C15
28
CL10A106MA8NRNC
10u 35V
Samsung Electro-Mechanics
C16, C17, C24, C25, C32, C33, C40, C41 +20
Show 6 more
QtyPartRefs
14
CL10B223KB8NNNC
22n 50V
Samsung Electro-Mechanics
C20, C28, C36, C44, C52, C60, C68, C76 +6
1
0603WAF2001T5E
2k
UNI-ROYAL
R1
2
0603WAF5100T5E
500
UNI-ROYAL
R2, R4
1
0603WAF1002T5E
10k
UNI-ROYAL
R3
28
PT1206FR-7W0R2L
0R11
YAGEO
R5, R6, R7, R8, R9, R10, R11, R12 +20
14
R
R33, R34, R35, R36, R37, R38, R39, R40 +6

MotionModuleSTM32R8 design files

The KiCad project lives in the griffotron/MotionModuleSTM32R8 repository on GitHub; these links point at the commit this page was built from.

MotionModuleSTM32R8: common questions

What microcontroller does the MotionModuleSTM32R8 use?

The MotionModuleSTM32R8 is built around the STM32F103R8T6, from the STM32 family.

How big is the MotionModuleSTM32R8 PCB?

The MotionModuleSTM32R8 measures 187.9 × 60.2 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the MotionModuleSTM32R8?

240 components, from 26 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the MotionModuleSTM32R8 design files?

From the griffotron/MotionModuleSTM32R8 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the MotionModuleSTM32R8 design in my own project?

Yes, under the terms of its MIT license, which griffotron chose for the repository.

Can I test firmware for the MotionModuleSTM32R8 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
