About the NES-IO-Board nessionator
NES-IO-Board nessionator is an open source PCB design by KabukiFlux, published on GitHub under the BSD-3-Clause license. It is a 2-layer board measuring 74.4 × 72.8 mm, with 19 components from 17 distinct parts.
Other key parts include the P7805-2000-S. By type, the board carries 9 connectors, 6 capacitors, 2 switches, 1 IC and 1 diode.
It belongs with the retro computing designs in this gallery.
From the project
Nessionator, the NESRGB mod output board
- Why - Description - Schematics - Install - Pics and final result
In order to preserve the Nintendo Entertainment System some actions are required like the recapping of the components cleaning, etc..., one way to ensure compatibility with modern TVs and improve the image as well is by installing the Tim Worthington's NESRGB board, which interfaces between the PPU and a CPLD to convert digital into analog signals with multiple palettes.

Main components on the NES-IO-Board nessionator
NES-IO-Board nessionator bill of materials (BOM)
19 components, 17 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | P7805-2000-S | 3-SIP_Module_V7805-2000 | U1 |
| 1 | PJ-102BH | BarrelJack_NES | J1 |
| 1 | GND_PAD | Pin_D1.3mm_L11.0mm | J2 |
| 1 | Conn_NESRGB_TW | CONN_NESRGB_TW | J3 |
| 1 | Conn_NES_RF | RF_CONN_NES | J4 |
| 1 | RGBNES_POWER | PinHeader_1x02_P2.54mm_Vertical | J5 |
| 1 | RCA CVBS | CUI_RCJ-043 | J6 |
| 1 | RCA AUDIO | CUI_RCJ-043 | J7 |
| 1 | MD-90SM | CUI_MD-90SM | J8 |
| 1 | Conn_Palette | PinHeader_1x04_P2.54mm_Vertical | J9 |
| 1 | EG2319 | EG2319 | SW1 |
| 1 | SYNC | SW_SPDT_PCM12 | SW2 |
| 1 | DF206ST-G | Diode_Bridge_Vishay_DFS | D1 |
| 1 | 2200uF | CP_Radial_D16.0mm_P7.50mm | C1 |
| 3 | 10nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C2, C4, C5 |
| 1 | 100uF | CP_EIA-7343-43_Kemet-X_Pad2.25x2.55mm_HandSolder | C3 |
| 1 | 22μF | CP_EIA-6032-28_Kemet-C_Pad2.25x2.35mm_HandSolder | C6 |
NES-IO-Board nessionator design files
The KiCad project lives in the KabukiFlux/NES-IO-Board-nessionator repository on GitHub; these links point at the commit this page was built from.
- Layoutkicad/Nes_xieles.kicad_pcb
- Schematickicad/Nes_xieles.kicad_sch
NES-IO-Board nessionator: common questions
How big is the NES-IO-Board nessionator?
The NES-IO-Board nessionator measures 74.4 × 72.8 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the NES-IO-Board nessionator?
19 components, from 17 distinct parts. The full bill of materials is listed on this page.
Where can I download the NES-IO-Board nessionator design files?
From the KabukiFlux/NES-IO-Board-nessionator repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the NES-IO-Board nessionator design in my own project?
Yes, under the terms of its BSD-3-Clause license, which KabukiFlux chose for the repository.
