PCB MillBurn layout, top view — open source board by kitecraft

About the PCB MillBurn

PCB MillBurn is an open source PCB design by kitecraft, published on GitHub under the MIT license. It is a 2-layer board measuring 68.6 × 66 mm, with 5 components from 3 distinct parts.

It belongs with the robotics & motion designs in this gallery.

From the project

A cross platform application for converting Gerber files into G-Code and SVG files for milling and/or laser engravers.

Drop a folder of Gerbers on the window. The board appears. Tell each layer what it should become. Press Export.

- Mill it. Isolation routing, drilling one file per bit, slots and oversized holes routed with an end mill, soldermask relief, cut-out with tabs — and, if you like, the copper-clad cut to size first so its edges become the datum for everything after. - Burn it. Laser-ready SVG at true 1:1 millimetres, for LightBurn or Inkscape. - Or both. Make the copper with the laser, then drill and cut out on the mill. Same board, same origin, same export — and a drill alignment test that lands…

PCB MillBurn, from the project README
From the project README

PCB MillBurn bill of materials (BOM)

5 components, 3 distinct parts.

QtyPartRefs
2
Conn_01x10
J1, J2
2
Conn_01x10
J3, J4
1
Barrel_Jack_MountingPin
J5

PCB MillBurn design files

The KiCad project lives in the kitecraft/PCB_MillBurn repository on GitHub; these links point at the commit this page was built from.

PCB MillBurn: common questions

How big is the PCB MillBurn?

The PCB MillBurn measures 68.6 × 66 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the PCB MillBurn?

5 components, from 3 distinct parts. The full bill of materials is listed on this page.

Where can I download the PCB MillBurn design files?

From the kitecraft/PCB_MillBurn repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the PCB MillBurn design in my own project?

Yes, under the terms of its MIT license, which kitecraft chose for the repository.
