3E-300015-32 (Female 90 Mini DIN 10)

KytorIndustries·minidin-breakout·pcb/3E-300015-32 (Female 90 Mini DIN 10)/3E-300015-32 (Female 90 Mini DIN 10).kicad_pcb

3E-300015-32 (Female 90 Mini DIN 10) PCB layout, top view — open source board by KytorIndustries

About the 3E-300015-32 (Female 90 Mini DIN 10) PCB

3E-300015-32 (Female 90 Mini DIN 10) is an open source PCB design by KytorIndustries, published on GitHub. It is a 2-layer board measuring 29.1 × 18.9 mm, with 2 components from 2 distinct parts.

It belongs with the dev boards & breakouts designs in this gallery.

From the project

Mini-DIN breakout kit for 8p, 9p, 10p type cables.

Each pin is routed to a labeled breakout that is compatible with a 2.54 mm (0.100″) breakaway male header, signal labels adhere to the following conventions:

- Mini-DIN 8, XRGB-mini - Mini-DIN 9, Sega Genesis (Mega Drive) Model 2 - Mini-DIN 10, Sega Saturn

3E-300015-32 (Female 90 Mini DIN 10), from the project README
From the project README

3E-300015-32 (Female 90 Mini DIN 10) bill of materials (BOM)

2 components, 2 distinct parts.

QtyPartRefs
1
Mini-DIN-10
J1
1
Conn_01x11_Pin
J2

3E-300015-32 (Female 90 Mini DIN 10) design files

The KiCad project lives in the KytorIndustries/minidin-breakout repository on GitHub; these links point at the commit this page was built from.

3E-300015-32 (Female 90 Mini DIN 10): common questions

How big is the 3E-300015-32 (Female 90 Mini DIN 10) PCB?

The 3E-300015-32 (Female 90 Mini DIN 10) measures 29.1 × 18.9 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the 3E-300015-32 (Female 90 Mini DIN 10)?

2 components, from 2 distinct parts. The full bill of materials is listed on this page.

Where can I download the 3E-300015-32 (Female 90 Mini DIN 10) design files?

From the KytorIndustries/minidin-breakout repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the 3E-300015-32 (Female 90 Mini DIN 10) design in my own project?

The repository has no license, so all rights stay with KytorIndustries. Use it as a reference, and ask the author before reusing the design.
