2020 2021-Demo4all PCB layout, top view — open source AVR/Arduino board by MOSH-Insa-Toulouse

About the 2020 2021-Demo4all PCB

2020 2021-Demo4all is an open source AVR/Arduino PCB design by MOSH-Insa-Toulouse, published on GitHub under the MIT license. It is a 2-layer board measuring 68.6 × 53.3 mm, with 16 components from 7 distinct parts.

Its main chip is the Arduino_1pin, from the AVR/Arduino family. By type, the board carries 8 connectors, 4 diodes and 4 resistors.

It belongs with the dev boards & breakouts designs in this gallery.

From the project

My Project

- [x] Ajouter de nouveaux fichiers - [x] Les ajouter à l'index de suivi - [x] Faire un commit (en local sur mon PC) - [x] Pousser le ou les commit vers le serveur - [x] Créer une nouvelle branche - [x] Basculer sur cette branche

- [x] Créer un projet de PCB pour réaliser une shield Arduino - [x] Saisi du schéma - [x] Vérification des tests électriques ERC - [x] Association des empreintes de composants avec leur boitier - [x] Génération de la netlist - [x] Conception de la carte électronique - [x] Importation de la netlist - [x] Placement des composants - [x] Définir les contraintes de…

2020 2021-Demo4all, from the project README
From the project README

2020 2021-Demo4all bill of materials (BOM)

16 components, 7 distinct parts.

QtyPartRefs
1
Power
P1
1
Analog
P2
1
Digital
P3
1
Digital
P4
4
CONN_01X01
P5, P6, P7, P8
4
LED
D1, D2, D3, D4
4
470
R1, R2, R3, R4

2020 2021-Demo4all design files

The KiCad project lives in the MOSH-Insa-Toulouse/2020_2021-Demo4all repository on GitHub; these links point at the commit this page was built from.

2020 2021-Demo4all: common questions

What microcontroller does the 2020 2021-Demo4all use?

The 2020 2021-Demo4all is built around the Arduino_1pin, from the AVR/Arduino family.

How big is the 2020 2021-Demo4all PCB?

The 2020 2021-Demo4all measures 68.6 × 53.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the 2020 2021-Demo4all?

16 components, from 7 distinct parts. The full bill of materials is listed on this page.

Where can I download the 2020 2021-Demo4all design files?

From the MOSH-Insa-Toulouse/2020_2021-Demo4all repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the 2020 2021-Demo4all design in my own project?

Yes, under the terms of its MIT license, which MOSH-Insa-Toulouse chose for the repository.

Can I test firmware for the 2020 2021-Demo4all without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
