2021-22 CapteurGraphite HOTTON LAMY PCB layout, top view — open source AVR/Arduino board by MOSH-Insa-Toulouse

About the 2021-22 CapteurGraphite HOTTON LAMY PCB

2021-22 CapteurGraphite HOTTON LAMY is an open source AVR/Arduino PCB design by MOSH-Insa-Toulouse, published on GitHub. It is a 2-layer board measuring 68.6 × 57 mm, with 22 components from 15 distinct parts.

Its main chip is the Arduino_1pin, from the AVR/Arduino family. Other key parts include the OLED, Bluetooth, LTC1050 and Encodeur_ROT. By type, the board carries 8 connectors, 6 resistors, 4 ICs and 4 capacitors.

From the project

*** ## 1. Description du projet, objectifs et livrables

*** ## 1. Description du projet, objectifs et livrables

Nous avons également créé un APK Android permettant d'afficher la valeur de la résistance mesurée sur un smartphone.

Enfin nous avons conçu un banc de test pour notre capteur afin de rédiger une datasheet associée et pouvoir proposer des solutions d'améliorations et les limites pour ce type de capteur. ***

2021-22 CapteurGraphite HOTTON LAMY, from the project README
