Displayunit
muccc·WomoLIN·Hardware/Displayunit/Displayunit.kicad_pcb
About the Displayunit PCB
Displayunit is an open source STM32 PCB design by muccc, published on GitHub under the GPL-3.0 license. It is a 4-layer board measuring 155 × 69.8 mm, with 143 components from 60 distinct parts.
Its main chip is the STM32L4R9ZITx, from the STM32 family. Other key parts include the TSC2007, MX25LM51245GXDI00, IS66WVH8M8BLL-100B1LI_0, TPS61165DRVR and USBLC6-2SC6. By type, the board carries 62 capacitors, 25 resistors, 16 inductors, 12 ICs, 11 connectors and 8 diodes.
From the project
Open Source Steuerung von LIN Bus Geräten im Caravan Bereich.
use: git clone https://github.com/muccc/WomoLIN.git
Neue Wege in der konfigurierbaren Software Entwicklung eines Community Projektes
Alle Infos findet Ihr in unserem Wiki hier auf Github.
https://github.com/muccc/WomoLIN/wiki/Home
18.Okt 2020 : 100. Mitglied in unserer Telegramgruppe 10.Aug 2020 : Inbetriebnahme Controlboard 2.0. 10.Juli 2020 : Controlboard 2.0. 10.Juni 2020 : Beginn Einbau Controlboard in Womo von Jan. 15.Mai 2020 : Erstes Displayboard Kleinserie. 11.Apr 2020 : Erste Inbetriebnahme Display Unit mit Display. 19.Mrz 2020 : Die ersten Hardware für die Display Unit ist…

Main components on the Displayunit
Displayunit bill of materials (BOM)
143 components, 60 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | TSC2007 | TSSOP-16_4.4x5mm_P0.65mm | IC1 |
| 1 | MX25LM51245GXDI00 | BGA24C100P5X5_600X800X35 | IC2 |
| 1 | IS66WVH8M8BLL-100B1LI_0 | BGA24C100P5X5_600X800X35 | IC3 |
| 1 | TPS61165DRVR | WSON-6-1EP_2x2mm_P0.65mm_EP1x1.6mm_ThermalVias | IC4 |
| 1 | STM32L4R9ZITx | LQFP-144_20x20mm_P0.5mm | U1 |
| 1 | USBLC6-2SC6 | SOT-23-6 | U2 |
| 1 | HD588E | SOIC-8_3.9x4.9mm_P1.27mm | U3 |
| 2 | TPS54160DGQR | SOP50P490X110-11N | U4, U5 |
| 1 | SN65HVD234 | SOIC-8_3.9x4.9mm_P1.27mm | U6 |
| 1 | AT25SF161-SHD-T | SO-8_5.3x6.2mm_P1.27mm | U7 |
| 1 | 24AA02E48T-I/OT | SOT-23-5 | U8 |
| 1 | 2N7002 | SOT-23 | Q1 |
| 1 | X322516MLB4SI | Crystal_SMD_3225-4Pin_3.2x2.5mm | Y1 |
| 1 | Q13FC1350000400 | Crystal_SMD_MicroCrystal_CC7V-T1A-2Pin_3.2x1.5mm | Y2 |
| 2 | 615008138221 | 615008138221 | J1, J2 |
| 1 | 54104-4031 | 54104-4031 | J3 |
| 1 | Conn_ARM_JTAG_SWD_20 | IDC-Header_2x10_P2.54mm_Vertical | J4 |
| 1 | 52271-0679 | 52271-0679 | J5 |
| 1 | Conn_02x06_Odd_Even | PinHeader_2x06_P2.54mm_Vertical | J6 |
| 2 | Conn_02x03_Odd_Even | Molex_Micro-Fit_3.0_43045-0612_2x03_P3.00mm_Vertical | J7, J11 |
Show 40 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | USB_B_Micro | USB_Micro-B_Molex-105017-0001 | J8 |
| 1 | Conn_02x05_Odd_Even | IDC-Header_2x05_P2.54mm_Vertical | J9 |
| 1 | ER-CON10HT-1 | ER-CON10HT-1 | J10 |
| 1 | Battery_Cell | QJ.BS-6 | BT1 |
| 1 | PFUF.150.2 30V 1.5A | Fuse_1210_3225Metric | F1 |
| 1 | Boot | TS-1187A | SW1 |
| 1 | Reset | TS-1187A | SW2 |
| 2 | SW_DIP_x01 | SW_SPST_CK_RS282G05A3 | SW3, SW4 |
| 1 | LED | LED_1206_3216Metric | D1 |
| 5 | B260A-13-F | D_SMB | D2, D3, D4, D6, D7 |
| 2 | NUP2105L | SOT-23 | D5, D8 |
| 11 | 100R | L_0603_1608Metric | FB1, FB2, FB3, FB4, FB5, FB6, FB7, FB8 +3 |
| 1 | BLM18PG121SN1D | L_0603_1608Metric | FB10 |
| 3 | 10uH | MWSA0503 | L1, L3, L4 |
| 1 | 2uH2 | MWSA0603 | L2 |
| 6 | 1u | C_1206_3216Metric | C1, C22, C26, C31, C37, C55 |
| 31 | 100n | C_0603_1608Metric | C2, C6, C7, C8, C9, C10, C11, C12 +23 |
| 4 | 6p8 | C_0603_1608Metric | C3, C4, C57, C58 |
| 1 | 1u | C_0603_1608Metric | C5 |
| 2 | 10u | C_1206_3216Metric | C15, C17 |
| 4 | 10n | C_0603_1608Metric | C16, C29, C38, C39 |
| 1 | 2u2 | C_1206_3216Metric | C21 |
| 2 | 3p3 | C_0603_1608Metric | C23, C24 |
| 2 | 2u2 | C_1210_3225Metric | C32, C33 |
| 1 | 4u7 | C_1210_3225Metric | C35 |
| 2 | 22u | C_1210_3225Metric | C42, C44 |
| 1 | 220n | C_0603_1608Metric | C43 |
| 2 | 10u | C_1210_3225Metric | C46, C49 |
| 1 | 1u | C_1210_3225Metric | C47 |
| 2 | 2n7 | C_0603_1608Metric | C64, C65 |
| 8 | 10k | R_0603_1608Metric | R1, R2, R3, R4, R5, R13, R15, R17 |
| 4 | 0R | R_0603_1608Metric | R6, R23, R24, R25 |
| 2 | 332k | R_0603_1608Metric | R7, R9 |
| 1 | 61k9 | R_0603_1608Metric | R8 |
| 1 | 1R1 | R_1206_3216Metric | R10 |
| 2 | 90k9 | R_0603_1608Metric | R11, R12 |
| 2 | 31k6 | R_0603_1608Metric | R14, R16 |
| 2 | 120R | R_0603_1608Metric | R18, R26 |
| 1 | 100k | R_0603_1608Metric | R20 |
| 2 | 76K8 | R_0603_1608Metric | R21, R22 |
Displayunit design files
The KiCad project lives in the muccc/WomoLIN repository on GitHub; these links point at the commit this page was built from.
Displayunit: common questions
What microcontroller does the Displayunit use?
The Displayunit is built around the STM32L4R9ZITx, from the STM32 family.
How big is the Displayunit PCB?
The Displayunit measures 155 × 69.8 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the Displayunit?
143 components, from 60 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Displayunit design files?
From the muccc/WomoLIN repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Displayunit design in my own project?
Yes, under the terms of its GPL-3.0 license, which muccc chose for the repository.
Can I test firmware for the Displayunit without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
