Photogates PCB layout, top view — open source AVR/Arduino board by nathab32

About the Photogates PCB

Photogates is an open source AVR/Arduino PCB design by nathab32, published on GitHub. It is a 2-layer board measuring 92 × 67.8 mm, with 29 components from 15 distinct parts.

Its main chip is the ARDUINO_DIGITAL_0_7, from the AVR/Arduino family. Other key parts include the SPST-NO Switch. By type, the board carries 9 resistors, 8 connectors, 5 capacitors, 3 ICs and 2 transistors.

It belongs with the displays & leds designs in this gallery.

From the project

Photogates allow precise, automatic timing of objects moving between two points. The photogates trigger automatically when a laser beam is interrupted, providing much faster response times than a human ever could with a stopwatch.

Photogates allow precise, automatic timing of objects moving between two points. The photogates trigger automatically when a laser beam is interrupted, providing much faster response times than a human ever could with a stopwatch.

This specific project was inspired by my Science Olympiad team's lack of a photogate for the timing events. Commonly available solutions online cost at least $50, with high resolution ones costing hundreds of dollars. This design seeks to lower the barrier to precise timing by using commonly available parts and 3D printed materials for a cost-effective design. The…

Photogates, from the project README
From the project README

Main components on the Photogates

SPST-NO Switch

Photogates bill of materials (BOM)

29 components, 15 distinct parts — part numbers from the project's BOM.

QtyPartRefs
3
SPST-NO Switch
U1, U2, U3
2
2N3904
Q3, Q4
1
ARDUINO_DIGITAL_0_7
Arduino_Digital_0_7
J1
1
ARDUINO_DIGITAL_8_13
Arduino_Digital_8_13
J2
1
Arduino_Power
J3
1
Arduino_Analog_IN
J4
4
CONN_01X02_PIN
Conn_01x02_Pin
J5, J6, J7, J8
1
WC1602A
DS1
1
10K
10k
RV1
1
1u
C1
4
0.1U
0.1u
C2, C3, C4, C5
1
220
R1
2
100K
100k
R2, R3
4
1k
R4, R5, R7, R8
2
100
R6, R9
