Bottom PCB layout, top view — open source board by not-sample-text

About the Bottom PCB

Bottom is an open source PCB design by not-sample-text, published on GitHub. It is a 2-layer board measuring 65 × 120 mm, with 47 components from 7 distinct parts.

Other key parts include the TPS22918DBVR. By type, the board carries 22 resistors, 12 capacitors, 10 diodes, 2 ICs and 1 connector.

It belongs with the iot & wireless and displays & leds designs in this gallery.

From the project

This repository represents the final version submitted for my Bachelor's Thesis.

This repository represents the final version submitted for my Bachelor's Thesis.

Active development for this project has moved to ApexPad. Please refer to the new repository for the most recent updates, bug fixes, and feature development.

The PROS3 Macropad is a versatile, open-source 12-key macropad built around the powerful ESP32-S3. Designed as a university thesis project, it features a rotary encoder, OLED display, RGB underglow, and a complete software ecosystem for deep customization.

Bottom, from the project README
From the project README

Main components on the Bottom

TPS22918DBVR

Bottom bill of materials (BOM)

47 components, 7 distinct parts.

QtyPartRefs
1
TPS22918DBVR
IC1
1
~
U1
1
Conn_01x15_Socket
J1
10
SK6812MINI
D1, D2, D3, D4, D5, D6, D7, D8 +2
12
0.1uF
C1, C2, C3, C4, C5, C6, C7, C8 +4
12
10k
R1, R2, R3, R4, R5, R6, R7, R8 +4
10
220
R11, R12, R13, R14, R15, R16, R17, R18 +2

Bottom design files

The KiCad project lives in the not-sample-text/Proiect-Licenta repository on GitHub; these links point at the commit this page was built from.

Bottom: common questions

How big is the Bottom PCB?

The Bottom measures 65 × 120 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Bottom?

47 components, from 7 distinct parts. The full bill of materials is listed on this page.

Where can I download the Bottom design files?

From the not-sample-text/Proiect-Licenta repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Bottom design in my own project?

The repository has no license, so all rights stay with not-sample-text. Use it as a reference, and ask the author before reusing the design.
