BRICOLEUR PCB layout, top view — open source Silicon Labs board by NTNU-TDT4295

About the BRICOLEUR PCB

BRICOLEUR is an open source Silicon Labs PCB design by NTNU-TDT4295, published on GitHub. It is a 2-layer board measuring 124.5 × 66 mm, with 78 components from 33 distinct parts.

Its main chip is the EFM32GG980, from the Silicon Labs family. Other key parts include the Ultrasonic-LV-EZ0, PYNQ-Shield-Bricoleur-pcb-cache, Arducam-OV5642, UART_BOOT and IP4220CZ6. By type, the board carries 20 diodes, 19 capacitors, 17 resistors, 10 ICs, 4 connectors and 4 switches.

From the project

This is the collision detection group's final submission for the course TDT4295 Computer Design Project 2018. This course aims to give students an introduction to the process of designing physical computer solutions, from start to finish. The project was completed on a budget of

This is the collision detection group's final submission for the course TDT4295 Computer Design Project 2018. This course aims to give students an introduction to the process of designing physical computer solutions, from start to finish. The project was completed on a budget of 10000 NOK, of which 5400 NOK were spent.

BRICOLEUR, from the project README
From the project README

Main components on the BRICOLEUR

Ultrasonic-LV-EZ0PYNQ-Shield-Bricoleur-pcb-cacheArducam-OV5642EFM32GG980UART_BOOTIP4220CZ6SW_DP3T

BRICOLEUR bill of materials (BOM)

78 components, 33 distinct parts.

QtyPartRefs
3
Ultrasonic-LV-EZ0
U1, U3, U4
1
PYNQ-Shield-Bricoleur-pcb-cache
U2
2
Arducam-OV5642
U5, U6
1
EFM32GG980
U7
1
UART_BOOT
U8
1
IP4220CZ6
U9
1
SW_DP3T
U11
1
ABM2-48.000MHZ-D4YF-T
Y1
1
USB_B_Micro
J1
1
Conn_02x10_Odd_Even
J2
2
Conn_02x03_Odd_Even
J3, J4
4
SW_Push
SW2, SW3, SW4, SW5
1
Test_VMCU
TP1
3
LED
D1, D2, D3
17
BAT54S
D4, D5, D6, D7, D8, D9, D10, D11 +9
1
220R 2A CBF221HC
L1
1
CBF102WB
L2
1
1U
C1
1
4U7
C2
7
100N
C3, C8, C9, C10, C11, C12, C17
Show 13 more
QtyPartRefs
1
1uF
C4
2
10U
C5, C13
2
10N
C6, C7
3
1N
C14, C15, C16
2
27p
C18, C19
4
100R
R1, R11, R12, R13
2
15R
R2, R3
1
1R
R4
3
1M
R5, R6, R7
1
3K
R8
2
3K
R9, R10
3
100K
R14, R15, R17
1
10K
R16

BRICOLEUR design files

The KiCad project lives in the NTNU-TDT4295/BRICOLEUR repository on GitHub; these links point at the commit this page was built from.

BRICOLEUR: common questions

What microcontroller does the BRICOLEUR use?

The BRICOLEUR is built around the EFM32GG980, from the Silicon Labs family.

How big is the BRICOLEUR PCB?

The BRICOLEUR measures 124.5 × 66 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the BRICOLEUR?

78 components, from 33 distinct parts. The full bill of materials is listed on this page.

Where can I download the BRICOLEUR design files?

From the NTNU-TDT4295/BRICOLEUR repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the BRICOLEUR design in my own project?

The repository has no license, so all rights stay with NTNU-TDT4295. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the BRICOLEUR without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug Silicon Labs firmware against it before you order a PCB.
