Robot PCB layout, top view — open source board by PREN1718-G03

About the Robot PCB

Robot is an open source PCB design by PREN1718-G03, published on GitHub under the MIT license. It is a 2-layer board measuring 65 × 56.5 mm, with 2 components from 2 distinct parts.

It belongs with the dev boards & breakouts and robotics & motion designs in this gallery.

From the project

KiCad files for manufacturing PCB

Raspberry Pi B+ Hat ============================

Expansion Board ----------------------------

This is a project template for a Raspberry Pi B+ Hat.

This base project includes a PCB edge defined according to this specification. Both a thru-hole and a surface mount connector are provided, along with a different PCB edge for each. Just keep the PCB edge and connector type that you're using for your design and delete the others.

Robot, from the project README
From the project README

Robot bill of materials (BOM)

2 components, 2 distinct parts.

QtyPartRefs
1
RPi_GPIO
J1
1
RPi_GPIO
J2

Robot design files

The KiCad project lives in the PREN1718-G03/robot-pcb repository on GitHub; these links point at the commit this page was built from.
