Common Rail PT2000 board

rusefi·rusefi·hardware/Common_Rail_PT2000/Common_Rail_PT2000.kicad_pcb

Common Rail PT2000 board layout, top view — open source board by rusefi

Simulate this board

About the Common Rail PT2000 board

Common Rail PT2000 board is an open source PCB design by rusefi, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 61 × 136.5 mm, with 168 components from 45 distinct parts.

Other key parts include the MC33816. By type, the board carries 58 capacitors, 39 resistors, 28 diodes, 15 transistors, 12 connectors and 12 test points.

From the project

rusefi - GPL internal combustion engine control unit

See Connectors wiki page todo: move Connectors wiki page content into git

35 pin Mazda TCU 38 pin Chrysler NGC connector 48 pin Mazda Miata NA6 52 pin Mitsubishi Galant VR4 55 pin TE Lada 55 pin Motronic 1.5.x BMW/GM 60 pin Ford EEC-IV 64 pin Mazda Miata NA NB1, Honda Civic 68 pin Volkswagen Audi VAG 72 pin Mazda Miata NB2 88 pin Volkswagen Audi VAG 121 pin Volkswagen Audi VAG 134 pin BWM 154 pin Volkswagen Audi VAG

Common Rail PT2000 board, from the project README — From the project README

Main components on the Common Rail PT2000 board

Common Rail PT2000 board bill of materials (BOM)

168 components, 45 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
1	MC33816 PT2000	LQFP-80_12x12mm_Pitch0.5mmThermal	U4
4	BUK9230-100B	TO-252-2Lead	Q1, Q13, Q14, Q15
11	BUK9230-100B	TO-252-2Lead	Q2, Q3, Q4, Q5, Q6, Q7, Q8, Q9 +3
1	1MHZ 1MHz	Crystal_SMD_SeikoEpson_MC306-4pin_8.0x3.2mm	Y1
1	CONN_01X03	Pin_Header_Straight_1x03_Pitch2.54mm	J1
7	INJ_Term	TerminalBlock_bornier-2_P5.08mm	J2, J8, J9, J10, J11, J12, J13
1	CONN_02X08	Pin_Header_Straight_2x12_Pitch2.54mm	J4
1	CONN_01X03	Pin_Header_Straight_1x03_Pitch2.54mm	J5
1	CONN_01X03	Pin_Header_Straight_1x02_Pitch1.27mm	J6
1	CONN_01X01 Conn_01x01	Pin_Header_Straight_1x01_Pitch2.54mm	J15
1	Conn_01x01	PINTST	TP1
11	CONN_01X01 Conn_01x01	PINTST	TP2, TP3, TP4, TP23, TP24, TP101, TP102, TP103 +3
2	STPS2H100UY	D_SMB	D1, D3
1	SBR10200CTL	TO-252-2Lead	D2
16	LED_Small	LED_0805	D4, D5, D6, D7, D8, D18, D19, D20 +8
1	FFD10UP20S	TO-252-2Lead	D9
2	SBR10200CTL	TO-252-2Lead	D10, D11
6	STPS2H100UY	D_SMB	D12, D13, D14, D15, D16, D17
1	6UH 6uH	744710610-Inductor	L1
1	10UH 10uH	IHLP6767GZER100M01	L2

Show 25 more

Qty	Part	Footprint	Refs
1	100NF 0.33uF	C_0805	C1
1	10NF 0.33uF	C_0805	C2
3	100NF 1000pF	C_0805	C3, C5, C7
3	10NF 4700pF	C_0805	C4, C6, C18
4	0.1UF 0.1uF	C_0805	C8, C10, C11, C13
1	1UF 1uF	C_0805	C9
1	4.7UF 4.7uF	C_0805	C12
2	1000UF 1000uF	CP_Radial_D22.0mm_P10.00mm_SnapIn	C14, C15
2	220NF 0.22uF	C_0805	C16, C17
11	1000PF 1000pF	C_0805	C19, C35, C36, C37, C38, C55, C56, C57 +3
1	4700pF	C_0805	C20
2	390UF 390uF	CP_Radial_D16.0mm_P7.50mm	C21, C22
6	330PF 330pF	C_0805	C23, C24, C28, C59, C60, C73
2	0.22UF 0.22uF	C_0805	C25, C27
1	470PF 470pF	C_0805	C26
2	330pF	C_0805	C29, C30
5	0.33UF 0.33uF	C_0805	C39, C40, C41, C42, C64
10	4700PF 4700pF	C_0805	C43, C44, C45, C46, C47, C48, C49, C50 +2
4	10R	R_0805	R1, R2, R3, R4
2	0R015	R_1206_HandSoldering	R5, R6
16	1k	R_0805	R7, R8, R25, R27, R28, R29, R30, R31 +8
2	5.1R	R_0805	R9, R10
11	10R	R_0805	R11, R13, R14, R15, R16, R17, R18, R19 +3
1	0R010	R_1206_HandSoldering	R12
3	0R010 0R015	R_1206_HandSoldering	R21, R22, R26

Common Rail PT2000 board design files

The KiCad project lives in the rusefi/rusefi repository on GitHub; these links point at the commit this page was built from.

Common Rail PT2000 board: common questions

How big is the Common Rail PT2000 board?

The Common Rail PT2000 board measures 61 × 136.5 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Common Rail PT2000 board?

168 components, from 45 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Common Rail PT2000 board design files?

From the rusefi/rusefi repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Common Rail PT2000 board design in my own project?

Yes, under the terms of its GPL-3.0 license, which rusefi chose for the repository.
