PDB Board 0.2

thejamesrhodes·Hyades-Flight-Computer·Hardware/PCB Designs/PDB Board 0.2/PDB Board 0.2/PDB Board 0.2.kicad_pcb

PDB Board 0.2 layout, top view — open source board by thejamesrhodes

About the PDB Board 0.2

PDB Board 0.2 is an open source PCB design by thejamesrhodes, published on GitHub under the Apache-2.0 license. It is a 4-layer board measuring 50 × 50 mm, with 48 components from 30 distinct parts.

Other key parts include the TPS62135RGXR, IHLP2525CZER1R0M01 and AP2115R5-3.3TRG1. By type, the board carries 11 resistors, 9 capacitors, 4 connectors, 4 LEDs, 3 ICs and 2 test points.

It belongs with the robotics & motion designs in this gallery.

From the project

Full Hardware and Electronics design, Bare-metal GNC flight software for an actively attitude-controlled high-power rocket

Custom STM32H743 flight computer and GNC software for a roll-rate-stabilised high-power rocket.

This is an engineering project, not a product. The safety case, regulatory compliance, and airworthiness of any vehicle built from this material are the builder's sole responsibility.

The project is designed to: - Provide a modular active roll-rate damping system suitable for a wide range of high-power rockets. - Improve flight data quality by reducing excessive vehicle roll. - Improve parachute deployment reliability by limiting roll-induced line twist. - Provide a reusable avionics platform for…

PDB Board 0.2, from the project README
From the project README

Main components on the PDB Board 0.2

TPS62135RGXRIHLP2525CZER1R0M01AP2115R5-3.3TRG1

PDB Board 0.2 bill of materials (BOM)

48 components, 30 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
TPS62135RGXR
Texas Instruments
U1
1
IHLP2525CZER1R0M01
Vishay Intertech
U2
1
AP2115R5-3.3TRG1
U3
1
2N7002
Q1
1
SERVOPORT_06
ServoPort_06
J1
2
CONN_01X05
Conn_01x05
J2, J3
1
1-0201FBV0T
Conn_01x02
TAD
J4
1
Battery
BT1
1
38216300000
Littelfuse
F1
4
~
H1, H2, H3, H4
4
~
H5, H6, H7, H8
2
KH-1_27PH180-1X16P-L7_2
Shenzhen Kinghelm Elec
H9, H10
2
TestPoint_Flag
TP9, TP10
1
LED_0603_RED
LED_0603_Red
LED1
1
LED_0603_ORANGE
LED_0603_Orange
LED2
2
LED_0603_GREEN
LED_0603_Green
LED3, LED4
1
SMAJ12CA
D1
1
SS34
D2
3
100NF
100nF
Samsung Electro-Mechanics
C1, C7, C8
4
10UF
10uF
Samsung Electro-Mechanics
C2, C3, C4, C5
Show 10 more
QtyPartRefs
1
1000UF_16V
1000uF_16V
C6
1
2.2NF
2.2nF
FH(Guangdong Fenghua Advanced Tech)
C19
2
100kΩ
UNI-ROYAL(Uniroyal Elec)
R1, R11
1
100Ω
UNI-ROYAL(Uniroyal Elec)
R2
1
9.1kΩ
UNI-ROYAL(Uniroyal Elec)
R3
1
56kΩ
UNI-ROYAL(Uniroyal Elec)
R4
1
180kΩ
UNI-ROYAL(Uniroyal Elec)
R5
1
10kΩ
UNI-ROYAL(Uniroyal Elec)
R6
1
470Ω
UNI-ROYAL(Uniroyal Elec)
R7
3
220Ω
UNI-ROYAL(Uniroyal Elec)
R8, R9, R10

PDB Board 0.2 design files

The KiCad project lives in the thejamesrhodes/Hyades-Flight-Computer repository on GitHub; these links point at the commit this page was built from.

PDB Board 0.2: common questions

How big is the PDB Board 0.2?

The PDB Board 0.2 measures 50 × 50 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the PDB Board 0.2?

48 components, from 30 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the PDB Board 0.2 design files?

From the thejamesrhodes/Hyades-Flight-Computer repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the PDB Board 0.2 design in my own project?

Yes, under the terms of its Apache-2.0 license, which thejamesrhodes chose for the repository.
