HHKB-Lite-2-Teensy
About the HHKB-Lite-2-Teensy PCB
HHKB-Lite-2-Teensy is an open source NXP PCB design by thirteen37, published on GitHub. It is a 2-layer board measuring 72.4 × 48 mm, with 3 components from 3 distinct parts.
Its main chip is the Teensy2.0_(C), from the NXP family.
It belongs with the keyboards designs in this gallery.
From the project
Teensy 2 controller board replacement for HHKB Lite 2
This is a QMK-compatible replacement controller for the HHKB Lite 2, identified by model numbers PD-KB200W/U or PD-KB200B/U.
This Lite version of the HHKB is a membrane keyboard and not exactly popular compared to more expensive Professional versions that use Topre switches. But the wiring is simple and is a good first project for modding commercial keyboards.
Main components on the HHKB-Lite-2-Teensy
HHKB-Lite-2-Teensy bill of materials (BOM)
3 components, 3 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | Teensy2.0_(C) | Teensy2.0 | U1 |
| 1 | Columns | Molex_Easy-On_39-53-2144_14-Contacts | J_Col1 |
| 1 | Rows | Molex_Easy-On_39-53-2084_8-Contacts | J_Row1 |
HHKB-Lite-2-Teensy design files
The KiCad project lives in the thirteen37/HHKB-Lite-2-Teensy repository on GitHub; these links point at the commit this page was built from.
- LayoutHHKB Lite 2.kicad_pcb
HHKB-Lite-2-Teensy: common questions
What microcontroller does the HHKB-Lite-2-Teensy use?
The HHKB-Lite-2-Teensy is built around the Teensy2.0_(C), from the NXP family.
How big is the HHKB-Lite-2-Teensy PCB?
The HHKB-Lite-2-Teensy measures 72.4 × 48 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the HHKB-Lite-2-Teensy?
3 components, from 3 distinct parts. The full bill of materials is listed on this page.
Where can I download the HHKB-Lite-2-Teensy design files?
From the thirteen37/HHKB-Lite-2-Teensy repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the HHKB-Lite-2-Teensy design in my own project?
The repository has no license, so all rights stay with thirteen37. Use it as a reference, and ask the author before reusing the design.
Can I test firmware for the HHKB-Lite-2-Teensy without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug NXP firmware against it before you order a PCB.
