Rca connector

tvecera·ch32-projects·tinyboy/hw/rca-connector/rca-connector.kicad_pcb

Rca connector PCB layout, top view — open source board by tvecera

About the Rca connector PCB

Rca connector is an open source PCB design by tvecera, published on GitHub under the MIT license. It is a 2-layer board measuring 25 × 21.7 mm, with 4 components from 4 distinct parts.

By type, the board carries 2 connectors and 2 resistors.

It belongs with the displays & leds designs in this gallery.

From the project

Tinyboy console is based on the CH32V003-GameConsole project by Stefan Wagner. Instead of the now discontinued CH32V003, it uses the newer CH32V002J4M6 MCU. I used version 1.1 of the PCB design, which does not include the transistor for the buzzer.

Tinyboy console is based on the CH32V003-GameConsole project by Stefan Wagner. Instead of the now discontinued CH32V003, it uses the newer CH32V002J4M6 MCU. I used version 1.1 of the PCB design, which does not include the transistor for the buzzer.

- https://oshwlab.com/wagiminator/ch32v003j4m6-game-console - https://github.com/wagiminator/CH32V003-GameConsole/tree/main/hardware

Rca connector, from the project README
From the project README

Rca connector bill of materials (BOM)

4 components, 4 distinct parts.

QtyPartRefs
1
Conn_01x04
J1
1
RS-162-DD
J2
1
680
R1
1
330
R2

Rca connector design files

The KiCad project lives in the tvecera/ch32-projects repository on GitHub; these links point at the commit this page was built from.

Rca connector: common questions

How big is the Rca connector PCB?

The Rca connector measures 25 × 21.7 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Rca connector?

4 components, from 4 distinct parts. The full bill of materials is listed on this page.

Where can I download the Rca connector design files?

From the tvecera/ch32-projects repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Rca connector design in my own project?

Yes, under the terms of its MIT license, which tvecera chose for the repository.
