6502 Output Board

acwright·6502-VCS·Hardware/Output Board/Rev 1.0/Output Board.kicad_pcb

6502 Output Board layout, top view — open source board by acwright

About the 6502 Output Board

6502 Output Board is an open source PCB design by acwright, published on GitHub under the CERN-OHL-P-2.0 license. It is a 2-layer board measuring 100 × 100 mm, with 12 components from 5 distinct parts.

Other key parts include the 74HC138. By type, the board carries 9 capacitors, 2 ICs and 1 resistor.

It belongs with the retro computing designs in this gallery.

From the project

6502-VCS 8-Bit Retro Computer Project

An AC6502 retro-style 8-bit computer based on the 65C02 microprocessor.

- Overview - Architecture - Systems - Software - Hardware - Main Board - Revision History - Input Board - Output Board - ROM Cart - Flash Cart - Flash Helper - Firmware - IB Controller - CAD - Production - Schematics - Libraries - Bill of Materials - Main Board - Input Board - Output Board - ROM Cart (Rev 1.0a) - ROM Cart (Rev 1.0b) - Flash Cart (Rev 1.0) - Flash Helper (Rev 1.0) - License

6502 Output Board, from the project README
From the project README

Main components on the 6502 Output Board

74HC138

6502 Output Board bill of materials (BOM)

12 components, 5 distinct parts.

QtyPartRefs
2
74HC138
U3, U4
1
1uF
C1
2
2.2nF
C2, C3
6
100nF
C5, C6, C7, C8, C9, C10
1
1k
R1

6502 Output Board design files

The KiCad project lives in the acwright/6502-VCS repository on GitHub; these links point at the commit this page was built from.

6502 Output Board: common questions

How big is the 6502 Output Board?

The 6502 Output Board measures 100 × 100 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the 6502 Output Board?

12 components, from 5 distinct parts. The full bill of materials is listed on this page.

Where can I download the 6502 Output Board design files?

From the acwright/6502-VCS repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the 6502 Output Board design in my own project?

Yes, under the terms of its CERN-OHL-P-2.0 license, which acwright chose for the repository.
