Controller
About the Controller PCB
Controller is an open source PCB design by adoble, published on GitHub. It is a 2-layer board measuring 71.1 × 73.9 mm, with 20 components from 16 distinct parts.
Other key parts include the TSR_1-2433. By type, the board carries 11 connectors, 3 ICs, 3 resistors, 2 diodes and 1 switch.
It belongs with the audio, rf & radio and iot & wireless designs in this gallery.
From the project
A digital modular audio system
An class D amplifier module that can select other digital sources (I2S, S/PDIF).
Select sources Receive input fron the volume control and adjust the volume over the DSP. Receive input from the button banks. These are used to interact with the display. Interface with an (Airlift) Wifi board over an extended SPI interface. This is used to download station lists and also to control the internet radio module.
Main components on the Controller
Controller bill of materials (BOM)
20 components, 16 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 3 | TSR_1-2433 | Converter_DCDC_TRACO_TSR-1_THT | U2, U3, U5 |
| 1 | Conn_02x15_Odd_Even | PinSocket_2x15_P2.54mm_Vertical | J1 |
| 2 | Conn_01x20 | PinSocket_1x20_P2.54mm_Vertical | J2, J3 |
| 1 | Conn_01x02 | JST_XH_B2B-XH-A_1x02_P2.50mm_Vertical | J4 |
| 1 | conn_vol | JST_PH_B5B-PH-K_1x05_P2.00mm_Vertical | J5 |
| 1 | conn_bl | JST_PH_B5B-PH-K_1x05_P2.00mm_Vertical | J6 |
| 1 | conn_br | JST_PH_B5B-PH-K_1x05_P2.00mm_Vertical | J7 |
| 1 | conn_dsp | JST_PH_B4B-PH-K_1x04_P2.00mm_Vertical | J8 |
| 1 | conn_i2s_mplx | JST_PH_B4B-PH-K_1x04_P2.00mm_Vertical | J9 |
| 1 | conn_wifi | JST_PH_B8B-PH-K_1x08_P2.00mm_Vertical | J10 |
| 1 | conn_gpio | PinHeader_1x04_P2.54mm_Vertical | J11 |
| 1 | RESET | SW_PUSH_6mm_H4.3mm | SW1 |
| 1 | D_Schottky | D_DO-15_P12.70mm_Horizontal | D1 |
| 1 | 1N4007 | D_DO-41_SOD81_P10.16mm_Horizontal | D2 |
| 1 | 10k | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R1 |
| 2 | 2.2K | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R2, R3 |
Controller design files
The KiCad project lives in the adoble/modular-audio repository on GitHub; these links point at the commit this page was built from.
Controller: common questions
How big is the Controller PCB?
The Controller measures 71.1 × 73.9 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Controller?
20 components, from 16 distinct parts. The full bill of materials is listed on this page.
Where can I download the Controller design files?
From the adoble/modular-audio repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Controller design in my own project?
The repository has no license, so all rights stay with adoble. Use it as a reference, and ask the author before reusing the design.
