Macropad attempt number-4
alsono·macropad-attempt-number-4·pcb/hackpad.kicad_pcb
About the Macropad attempt number-4 PCB
Macropad attempt number-4 is an open source PCB design by alsono, published on GitHub. It is a 2-layer board measuring 98.4 × 69.2 mm, with 6 components from 3 distinct parts.
Other key parts include the MOUDLE-SEEEDUINO-XIAO and ER_OLEDM0.91_1x-I2C. By type, the board carries 4 switches and 2 ICs.
It belongs with the keyboards and displays & leds designs in this gallery.
From the project
schematic and pcb designs made using kicad you can order the pcb from jlcpcb using the gerber zip file in the productions folder

Main components on the Macropad attempt number-4
Macropad attempt number-4 bill of materials (BOM)
6 components, 3 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | MOUDLE-SEEEDUINO-XIAO | XIAO-Generic-Hybrid-14P-2.54-21X17.8MM | U1 |
| 1 | ER_OLEDM0.91_1x-I2C | ER_OLEDM0.91_1x-I2C | U2 |
| 4 | SW_Push | SW_Cherry_MX_1.00u_PCB | SW1, SW2, SW3, SW4 |
Macropad attempt number-4 design files
The KiCad project lives in the alsono/macropad-attempt-number-4 repository on GitHub; these links point at the commit this page was built from.
- Layoutpcb/hackpad.kicad_pcb
- Schematicpcb/hackpad.kicad_sch
Macropad attempt number-4: common questions
How big is the Macropad attempt number-4 PCB?
The Macropad attempt number-4 measures 98.4 × 69.2 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Macropad attempt number-4?
6 components, from 3 distinct parts. The full bill of materials is listed on this page.
Where can I download the Macropad attempt number-4 design files?
From the alsono/macropad-attempt-number-4 repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Macropad attempt number-4 design in my own project?
The repository has no license, so all rights stay with alsono. Use it as a reference, and ask the author before reusing the design.
