WP-2 IC-Card BUS TAP

bkw777·WP-2_IC-Card·PCB/WP-2_IC-Card_BUS_TAP.kicad_pcb

WP-2 IC-Card BUS TAP PCB layout, top view — open source board by bkw777
Simulate this board

About the WP-2 IC-Card BUS TAP PCB

WP-2 IC-Card BUS TAP is an open source PCB design by bkw777, published on GitHub under the Custom license license. It is a 2-layer board measuring 59.4 × 81.9 mm, with 4 components from 4 distinct parts.

By type, the board carries 3 connectors and 1 jumper.

It belongs with the dev boards & breakouts designs in this gallery.

From the project

IC Cards for TANDY WP-2

The TANDY WP-2 and other clones of the Citizen CBM-10WP have an expansion slot that accepts "IC Cards".

Here are a few different cards to fit that slot.

A battery-backed SRAM card like the original cards A non-volatile MRAM card, a RAM card that doesn't need a battery A ROM card, there is new software that runs from a rom card but no known images of any old original rom cards A programming adapter that can read and write both the RAM and ROM cards outside of the WP-2 * A bus-tap/breakout card to allow connecting the bus to a breadboard or logic analyser etc

WP-2 IC-Card BUS TAP, from the project README
From the project README

WP-2 IC-Card BUS TAP bill of materials (BOM)

4 components, 4 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
SMS-138-01-G-S
J1
1
PRPC019DAAN-RC
Conn_02x20_Odd_Even
J2
1
TMS-138-01
J3
1
VCC
JP1

WP-2 IC-Card BUS TAP design files

The KiCad project lives in the bkw777/WP-2_IC-Card repository on GitHub; these links point at the commit this page was built from.

WP-2 IC-Card BUS TAP: common questions

How big is the WP-2 IC-Card BUS TAP PCB?

The WP-2 IC-Card BUS TAP measures 59.4 × 81.9 mm, has 2 copper layers and is 1.2 mm thick.

How many components are on the WP-2 IC-Card BUS TAP?

4 components, from 4 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the WP-2 IC-Card BUS TAP design files?

From the bkw777/WP-2_IC-Card repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the WP-2 IC-Card BUS TAP design in my own project?

It is published under Custom license, which limits how it may be reused; read the license before building on it.
