Hivee
About the Hivee PCB
Hivee is an open source PCB design by breadbee, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 11.4 × 31.8 mm, with 3 components from 2 distinct parts.
It belongs with the dev boards & breakouts and sensors designs in this gallery.
From the project
Breadboard-able Cortex A7 dev board
A very small, 32mm x 30mm, ARM Cortex A7 development board that costs about ~$10 to make in low quantities and can be assembled at home with a cheap hot air rework station. With a small adapter socket it can be mounted vertically in a standard breadboard.
The breadbee is based on a relatively unknown IP camera SoC, the MSC313E, from a company called MStar (now part of MediaTek as a subsidiary called SigmaStar). You might have never heard of MStar but you probably have one of their chips in your TV.
Hivee bill of materials (BOM)
3 components, 2 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | Conn_02x12_Odd_Even | PinSocket_2x12_P2.54mm_Vertical | J1 |
| 2 | Conn_01x12_Male | PinHeader_1x12_P2.54mm_Vertical | J2, J3 |
Hivee design files
The KiCad project lives in the breadbee/breadbee repository on GitHub; these links point at the commit this page was built from.
- Layouthivee/hivee.kicad_pcb
Hivee: common questions
How big is the Hivee PCB?
The Hivee measures 11.4 × 31.8 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Hivee?
3 components, from 2 distinct parts. The full bill of materials is listed on this page.
Where can I download the Hivee design files?
From the breadbee/breadbee repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the Hivee design in my own project?
Yes, under the terms of its GPL-3.0 license, which breadbee chose for the repository.
