Analog Amplifier Module Board

CarlosCraveiro·einstein-boltzmann·amplifiers/amplifiers.kicad_pcb

Analog Amplifier Module Board layout, top view — open source board by CarlosCraveiro

About the Analog Amplifier Module Board

Analog Amplifier Module Board is an open source PCB design by CarlosCraveiro, published on GitHub under the CERN-OHL-S-2.0 license. It is a 2-layer board measuring 23 × 16 mm, with 4 components from 3 distinct parts.

Other key parts include the ADA4898-2. By type, the board carries 3 connectors and 1 IC.

It belongs with the audio designs in this gallery.

From the project

Remake of the board of the 5-th EPO (2017), using KiCAD 7.0, to measure the Boltzmann constant through the analysis of the thermal noise of a resistor.

So the schematic ideia is not mine, I just adapt and documented it so I could manufacture the board.

The DRC Custom Rules used on this project came from a gist made by darkxst, Gist name: rules.txt.

- KiCAD version 7.0 - KiCAD Addon kicad-action-scripts (via stitching)

If you use nix, to have access to KiCAD 7.0, on the project's directory type:

Observation: I intend to continue working on the project, I just need time.

Analog Amplifier Module Board, from the project README
From the project README

Main components on the Analog Amplifier Module Board

ADA4898-2

Analog Amplifier Module Board bill of materials (BOM)

4 components, 3 distinct parts.

QtyPartRefs
1
ADA4898-2
U1
2
Conn_01x03_Pin
J1, J3
1
Conn_01x02_Pin
J2

Analog Amplifier Module Board design files

The KiCad project lives in the CarlosCraveiro/einstein-boltzmann repository on GitHub; these links point at the commit this page was built from.

Analog Amplifier Module Board: common questions

How big is the Analog Amplifier Module Board?

The Analog Amplifier Module Board measures 23 × 16 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Analog Amplifier Module Board?

4 components, from 3 distinct parts. The full bill of materials is listed on this page.

Where can I download the Analog Amplifier Module Board design files?

From the CarlosCraveiro/einstein-boltzmann repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Analog Amplifier Module Board design in my own project?

Yes, under the terms of its CERN-OHL-S-2.0 license, which CarlosCraveiro chose for the repository.
