Kicad oil level sensor

CrtomirJuren·KiCad-projects·kicad-oil-level-sensor/kicad-oil-level-sensor.kicad_pcb

Kicad oil level sensor PCB layout, top view — open source board by CrtomirJuren
Simulate this board

About the Kicad oil level sensor PCB

Kicad oil level sensor is an open source PCB design by CrtomirJuren, published on GitHub. It is a 2-layer board measuring 160 × 100 mm, with 37 components from 23 distinct parts.

Other key parts include the TLV2371P. By type, the board carries 13 relays, 10 connectors, 9 resistors, 3 jumpers and 2 ICs.

It belongs with the sensors and dev boards & breakouts designs in this gallery.

From the project

kicad projects backup C:\KiCad\projects

- compress gerber folder - upload and check: https://www.gerblook.org/

Create Folder and copy plugin to this directory

KiSymGen is a cross platform utility enabling users to generate kicad schematic symbols using a graphical tool. KiSymGen is developed based on imgui and GLFW3.

- Double click on the kisymgen.sln file which should open the project in visual studio.

Kicad oil level sensor, from the project README
From the project README

Main components on the Kicad oil level sensor

TLV2371P

Kicad oil level sensor bill of materials (BOM)

37 components, 23 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
TLV2371P
U1, U2
1
PROBES_DUT and SENSOR
J1
1
CH1_DIVIDER
J2
1
6-16V_PS_DUT
J3
1
PROBES_Ups
J4
1
Conn_01x03_Pin
J5
1
NI 9472 DO Control
J6
1
MEAS_SENSOR_SHUNT
J7
1
Screw_Terminal_01x08
J10
1
12V Electronics PS
J12
1
CH2_DIVIDER
J13
1
JUMP_Enable_ECU_PS
JP1
1
Jumper_2_Open
JP2
1
JUMP_Enable_R_delta
JP3
1
DIPxx-1Axx-12xD
K1
10
G6K-2
K2, K5, K6, K7, K8, K9, K10, K11 +2
1
TQ2-2M-24V
K3
1
SIL24-1A72-71D
K4
2
0.25
R1, R5
1
1
R2
Show 3 more
QtyPartRefs
1
2600
R4
1
15
R6
4
10k
R7, R8, R9, R10

Kicad oil level sensor design files

The KiCad project lives in the CrtomirJuren/KiCad-projects repository on GitHub; these links point at the commit this page was built from.

Kicad oil level sensor: common questions

How big is the Kicad oil level sensor PCB?

The Kicad oil level sensor measures 160 × 100 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Kicad oil level sensor?

37 components, from 23 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Kicad oil level sensor design files?

From the CrtomirJuren/KiCad-projects repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Kicad oil level sensor design in my own project?

The repository has no license, so all rights stay with CrtomirJuren. Use it as a reference, and ask the author before reusing the design.
