Chesapeake

About the Chesapeake PCB

Chesapeake is an open source RP2040/RP2350 PCB design by dashs20, published on GitHub. It is a board, with 44 components from 25 distinct parts.

Its main chip is the XIAO-RP2350-SMD, from the RP2040/RP2350 family. Other key parts include the LSM6DSV16XTR. By type, the board carries 12 modules, 5 capacitors, 4 resistors, 3 diodes, 2 ICs and 2 connectors.

It belongs with the robotics & motion and sensors designs in this gallery.

From the project

Drone flight software for custom flight controller

Chesapeake is a high-performance, modular embedded flight control firmware designed for the Seeed Studio XIAO RP2350 microcontroller. Built in C++ using PlatformIO with the Earle Philhower Arduino-Pico core, it implements state-of-the-art guidance, navigation, and control algorithms, leveraging Eigen for optimized vector mathematics, custom attitude estimation, and custom Hardware Abstraction Layer (HAL) drivers.

Main components on the Chesapeake

XIAO-RP2350-SMDLSM6DSV16XTR

Chesapeake bill of materials (BOM)

44 components, 25 distinct parts.

QtyPartRefs
1
XIAO-RP2350-SMD
U2
1
LSM6DSV16XTR
U3
8
conn
M1, M1g1, M2, M2g1, M3, M3g1, M4, M4g1
4
conn
M1p1, M2p1, M3p1, M4p1
1
Conn_01x02_Pin
q5v1
1
Conn_01x40
J1
1
BAT
J4
4
conn
BOOT1, CLK1, DIO1, RST1
1
~
ELRS1
1
conn
S5V1
2
conn
SGND1, SS1
1
gnd_bridge
nt1
1
Conn_01x02_Pin
qgnd1
4
conn
reg_5v_in1, reg_5v_out1, reg_gnd_in1, reg_gnd_out1
1
BLUE
D1
1
Diode_SMD:D_SMA
D2
1
1N5822
D3
1
10 uH
L1
1
1000 uF
C2
2
100nF
C3, C4
Show 5 more
QtyPartRefs
2
100 uF
C5, C6
1
9.1k
R1
1
220
R2
1
1k
R3
1
10k
R4

Chesapeake design files

The KiCad project lives in the dashs20/Chesapeake repository on GitHub; these links point at the commit this page was built from.

Chesapeake: common questions

What microcontroller does the Chesapeake use?

The Chesapeake is built around the XIAO-RP2350-SMD, from the RP2040/RP2350 family.

How many components are on the Chesapeake?

44 components, from 25 distinct parts. The full bill of materials is listed on this page.

Where can I download the Chesapeake design files?

From the dashs20/Chesapeake repository on GitHub, which has a netlist; the links under Design files point to each one.

Can I use the Chesapeake design in my own project?

The repository has no license, so all rights stay with dashs20. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Chesapeake without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
