Pecanpico10

DL7AD·pecanpico10·tracker/hardware/10b/pecanpico10.kicad_pcb

Pecanpico10 PCB layout, top view — open source STM32 board by DL7AD
Simulate this board

About the Pecanpico10 PCB

Pecanpico10 is an open source STM32 PCB design by DL7AD, published on GitHub under the Custom license license. It is a 2-layer board measuring 23 × 50 mm, with 119 components from 59 distinct parts.

Its main chip is the STM32F413RHT6, from the STM32 family. Other key parts include the SPV1040T, TPS62260DRVR, ADP322ACPZ-115-R7, Si4464-B1B-FM and EVA-7M or EVA-M8. By type, the board carries 49 capacitors, 30 resistors, 10 ICs, 9 inductors, 7 diodes and 5 connectors.

It belongs with the rf & radio, power & battery and sensors designs in this gallery.

From the project

A lightweight APRS tracker and digipeater

The main features are: - GPS Tracking - Taking pictures - APRS receiption and transmission - Measuring Temperature/Airpressure/Humidity (up to 3 separate sensors) - Digipeating

Powering: The Pecan Pico 10 can be powered either by USB or by a single LiPO cell which are charged with solar cells. In power safe mode, it uses 50mW and around 150-200mW in normal operation. dive deeper

Pecanpico10, from the project README
From the project README

Main components on the Pecanpico10

SPV1040TTPS62260DRVRADP322ACPZ-115-R7Si4464-B1B-FMSTM32F413RHT6EVA-7M or EVA-M8PAC1720-1-AIA-TRBME280AS213-92LF

Pecanpico10 bill of materials (BOM)

119 components, 59 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
SPV1040T
IC1
2
TPS62260DRVR
IC2, IC8
1
ADP322ACPZ-115-R7
IC3
1
Si4464-B1B-FM
IC4
1
STM32F413RHT6
IC5
1
EVA-7M or EVA-M8
IC6
1
PAC1720-1-AIA-TR
IC7
1
BME280
IC9
1
AS213-92LF
IC10
1
FDN306P
Q1
1
KT2016K26000BCW18ZAS
X1
1
SF2316H
X2
1
DM3AT-SF-PEJM5
J1
1
CONN_01X15
J2
1
CONN_01X25
P1
1
ZX62-B-5PA(33)
P3
1
SMA
P4
1
1575AT43A0040E
AE1
2
Pad
W1, W11
2
Testpad
W2, W3
Show 39 more
QtyPartRefs
1
Pad
W10
1
SDM100K30L-7
D1
2
red
D2, D7
2
green
D3, D5
1
yellow
D4
1
blue
D6
1
LPS6225-103
L1
2
LPS3015-222
L2, L7
1
470n
L3
2
56n
L4, L9
1
82n
L5
1
220n
L8
1
150n
L10
2
22u
C1, C31
1
1n
C2
5
10u
C3, C4, C6, C7, C21
5
22p
C5, C17, C24, C47, C50
10
2u2
C8, C9, C10, C11, C12, C13, C37, C39 +2
11
100n
C14, C20, C29, C30, C33, C35, C43, C44 +3
3
100p
C15, C16, C34
4
470p
C18, C19, C36, C42
1
3.3p
C25
1
15p
C26
1
1u
C28
2
10n
C32, C38
1
6.2p
C41
1
2.2p
C49
1
12p
C52
1
220k
R1
5
100k
R2, R8, R13, R17, R31
3
22k
R3, R5, R33
5
10k
R4, R6, R9, R14, R32
1
402k
R7
6
1k5
R10, R15, R19, R21, R27, R35
3
1k
R11, R29, R30
1
470k
R12
2
0R1
R18, R22
1
1M
R20
2
4k7
R25, R26

Pecanpico10 design files

The KiCad project lives in the DL7AD/pecanpico10 repository on GitHub; these links point at the commit this page was built from.

Pecanpico10: common questions

What microcontroller does the Pecanpico10 use?

The Pecanpico10 is built around the STM32F413RHT6, from the STM32 family.

How big is the Pecanpico10 PCB?

The Pecanpico10 measures 23 × 50 mm, has 2 copper layers and is 1 mm thick.

How many components are on the Pecanpico10?

119 components, from 59 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Pecanpico10 design files?

From the DL7AD/pecanpico10 repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Pecanpico10 design in my own project?

It is published under Custom license, which limits how it may be reused; read the license before building on it.
