About the LEDcube PCB

LEDcube is an open source STM32 PCB design by eurovibes, published on GitHub. It is a 2-layer board measuring 40 × 40 mm, with 23 components from 16 distinct parts.

Its main chip is the STM32F030F4Px, from the STM32 family. Other key parts include the AP1117-33 and SP3485CN. By type, the board carries 6 capacitors, 5 diodes, 3 ICs, 3 connectors, 3 resistors and 2 jumpers.

It belongs with the wearables designs in this gallery.

From the project

A RGB LED cube

LEDcube is provided under the terms of the CERN-OHL-S license version 2 as provided in the LICENSES/CERN-OHL-S-2.0 file.

Instead of adding license boilerplates to the individual files, LEDcube uses SPDX license identifiers, which are machine parseable and considered legaly equivalent.

The SPDX license identifier in LEDcube shall be added at the first possible line in a file which can contain a comment. This is normally the first line except for scripts. Scripts require the #!PATHTOINTERPRETER tag in the first line; place the SPDX identifier into the second line.

LEDcube, from the project README
From the project README

Main components on the LEDcube

AP1117-33STM32F030F4PxSP3485CN

LEDcube bill of materials (BOM)

23 components, 16 distinct parts.

QtyPartRefs
1
AP1117-33
U101
1
STM32F030F4Px
U102
1
SP3485CN
U103
1
16MHz
Y101
1
IN
J101
1
OUT
J102
1
JTAG
J103
1
NRST
JP101
1
BOOT0
JP102
1
BAT60A
D101
4
WS2812B
D102, D103, D104, D105
2
10µ
C101, C103
2
100n
C102, C104
2
9p
C105, C106
2
100k
R101, R102
1
1M
R103
