About the HDMItest PCB

HDMItest is an open source PCB design by fachat, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 40.1 × 29 mm, with 4 components from 4 distinct parts.

By type, the board carries 3 connectors and 1 jumper.

It belongs with the audio and retro computing designs in this gallery.

From the project

Note: this is a part of a larger set of repositories, with upet_family as the main repository.

Note: this is a part of a larger set of repositories, with upet_family as the main repository.

This is a re-incarnation of the Commodore PET computer(s) from the later 1970s.

It is build on a PCB that fits into a C64-II case (with extra cutouts for connectors), and has only parts that can still be obtained new in 2024/2025. A 3D-printed case is also available specific for the Ulti-PET PCB.

HDMItest, from the project README
From the project README

HDMItest bill of materials (BOM)

4 components, 4 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
C138388
HDMI_A
J1
1
CONN_02X06_ODD_EVEN
Conn_02x06_Odd_Even
J2
1
~
P11
1
JUMPER_2_OPEN
Jumper_2_Open
JP1

HDMItest design files

The KiCad project lives in the fachat/cbm_ultipet repository on GitHub; these links point at the commit this page was built from.

HDMItest: common questions

How big is the HDMItest PCB?

The HDMItest measures 40.1 × 29 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the HDMItest?

4 components, from 4 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the HDMItest design files?

From the fachat/cbm_ultipet repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the HDMItest design in my own project?

Yes, under the terms of its GPL-3.0 license, which fachat chose for the repository.
