Sherie PCB layout, top view — open source AVR/Arduino board by flora495

About the Sherie PCB

Sherie is an open source AVR/Arduino PCB design by flora495, published on GitHub. It is a 2-layer board measuring 278.3 × 81.9 mm, with 117 components from 23 distinct parts.

Its main chip is the ATMEGA32U4-A, from the AVR/Arduino family. Other key parts include the TPD4E05U06DQAR. By type, the board carries 47 switches, 47 diodes, 7 capacitors, 7 resistors, 2 ICs and 1 crystal.

It belongs with the keyboards designs in this gallery.

From the project

ATMEGA32U4直付の手順は以下を参照します。 [2]https://wiki.ai03.com/books/pcb-design/chapter/pcb-designer-guide

ATMEGA32U4直付の手順は以下を参照します。 [2]https://wiki.ai03.com/books/pcb-design/chapter/pcb-designer-guide

[3]https://taro-hayashi.github.io/LetsMakeaKeypadWithAtmega32u2/

typeC周りの回路 [4]https://github.com/Unified-Daughterboard/UDB-S

静電気対策（特に金属ケースの場合は参照） [5]https://gist.github.com/s-show/286ffb1f5d9c886b514ff7a37e6d8d37

ベタGNDとか [6]https://taro-hayashi.github.io/LetsMakeaKeypadWithAtmega32u2/

Sherie, from the project README
From the project README

Main components on the Sherie

ATMEGA32U4-ATPD4E05U06DQAR

Sherie bill of materials (BOM)

117 components, 23 distinct parts — part numbers from the project's BOM.
