About the Toro board

Toro board is an open source RP2040/RP2350 PCB design by idksarah, published on GitHub. It is a 2-layer board measuring 339.2 × 137 mm, with 135 components from 4 distinct parts.

Its main chip is the Pico, from the RP2040/RP2350 family. By type, the board carries 67 switches, 67 diodes and 1 IC.

It belongs with the keyboards designs in this gallery.

From the project

fully-custom 60% alice keyboard running on a raspberry pi pico

- jlcpcb total: 21.60 (pcb) + 20.00 (shipping) → $41.60 - aliexpress total: 16.66 + 26.69 + 7.00 + 3.73 + 3.74 + 3.92 → $61.74 - jlccnc total: 3.44 + 28.34 + 9.35 → $41.13

Toro board, from the project README — From the project README

Main components on the Toro board

Pico

Toro board bill of materials (BOM)

135 components, 4 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
1	Pico	RPi_Pico_SMD_TH	U1
66	Kailh_socket	Kailh_socket_MX	SW1, SW3, SW4, SW5, SW6, SW7, SW8, SW9 +58
1	RotaryEncoder_Switch	RotaryEncoder_Alps_EC12E-Switch_Vertical_H20mm	SW2
67	1N4148	D_DO-35_SOD27_P7.62mm_Horizontal	D2, D3, D4, D5, D6, D7, D8, D9 +59

Toro board design files

The KiCad project lives in the idksarah/toro-board repository on GitHub; these links point at the commit this page was built from.

Toro board: common questions

What microcontroller does the Toro board use?

The Toro board is built around the Pico, from the RP2040/RP2350 family.

How big is the Toro board?

The Toro board measures 339.2 × 137 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Toro board?

135 components, from 4 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Toro board design files?

From the idksarah/toro-board repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Toro board design in my own project?

The repository has no license, so all rights stay with idksarah. Use it as a reference, and ask the author before reusing the design.
