About the Tianyan PCB

Tianyan is an open source Raspberry Pi PCB design by Innaf0, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 62.2 × 120 mm, with 8 components from 7 distinct parts.

Its main chip is the RaspberryPi_Pico_W, from the Raspberry Pi family. By type, the board carries 3 switches, 1 IC, 1 module, 1 battery holder and 1 speaker.

From the project

and here's the backside with valo art again NOW BUILTTT:)

and here's the backside with valo art again NOW BUILTTT:)

Here's the front of my PCB w components:

AND here's my PCB without components so you can see the art!!

Here's my BOM!! | item: | price per unit: | quantity: | total price: | link: | |--------------------|-----------------|--------------|--------------|-------------------------------------------------------| | Display | $10.52 | 1 | $10.52 | https://www.aliexpress.com/item/1005005334824151.html | | Pi pico2 | $13.20 | 1 | $13.20 | https://www.aliexpress.com/item/1005009845096943.html | | DAC | $4.95 | 1 | $4.95 |…

Tianyan, from the project README
From the project README

Main components on the Tianyan

RaspberryPi_Pico_W

Tianyan bill of materials (BOM)

8 components, 7 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
~
U1
1
RaspberryPi_Pico_W
A1
1
Battery_Cell
BT1
1
~
DS1
1
Speaker
LS1
1
SW_Push
SW1
2
SW_Push
SW2, SW3

Tianyan design files

The KiCad project lives in the Innaf0/Tianyan repository on GitHub; these links point at the commit this page was built from.

Tianyan: common questions

What microcontroller does the Tianyan use?

The Tianyan is built around the RaspberryPi_Pico_W, from the Raspberry Pi family.

How big is the Tianyan PCB?

The Tianyan measures 62.2 × 120 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Tianyan?

8 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Tianyan design files?

From the Innaf0/Tianyan repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Tianyan design in my own project?

Yes, under the terms of its GPL-3.0 license, which Innaf0 chose for the repository.

Can I test firmware for the Tianyan without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug Raspberry Pi firmware against it before you order a PCB.
