About the Preenfm3 PCB

Preenfm3 is an open source PCB design by Ixox, published on GitHub. It is a 2-layer board measuring 208 × 95.7 mm, with 6 components from 3 distinct parts.

It belongs with the audio designs in this gallery.

From the project

Official repo of the preenfm3 FM synth

This enclosure for the preenfm3 is made from 2 3D printed pieces plus a PCB for the top surface.

The following is required to mount the enclosure. You can use M2.5 or M3. 2 x 15mm M/F for the lower front spacers 2 x 20mm M/F for the lower rear spacers 4 14mm M/M sapcers for the up spacers (between main PCB and top surface) 5 6mm M/F for the spacers between control board and main PCB

Preenfm3, from the project README
From the project README

Preenfm3 bill of materials (BOM)

6 components, 3 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
TFT / SD
J13
1
pfm3ControlBoard
CB1
4
MountingHole
H1, H2, H3, H4

Preenfm3 design files

The KiCad project lives in the Ixox/preenfm3 repository on GitHub; these links point at the commit this page was built from.

Preenfm3: common questions

How big is the Preenfm3 PCB?

The Preenfm3 measures 208 × 95.7 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Preenfm3?

6 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Preenfm3 design files?

From the Ixox/preenfm3 repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Preenfm3 design in my own project?

The repository has no license, so all rights stay with Ixox. Use it as a reference, and ask the author before reusing the design.
