Wio-SX1262 for ESP32S3

jadenvv·NULL·null_elec/OPL_Kicad_Library-master/Seeed Studio Wio SX1262 for XIAO ESP32S3/Wio-SX1262 for ESP32S3.kicad_pcb

Wio-SX1262 for ESP32S3 PCB layout, top view — open source board by jadenvv
Simulate this board

About the Wio-SX1262 for ESP32S3 PCB

Wio-SX1262 for ESP32S3 is an open source PCB design by jadenvv, published on GitHub. It is a 2-layer board measuring 17.8 × 21.4 mm, with 15 components from 10 distinct parts.

Other key parts include the Wio-SX1262. By type, the board carries 7 resistors, 3 connectors, 1 IC, 1 relay, 1 test point and 1 diode.

It belongs with the rf & radio and iot & wireless designs in this gallery.

From the project

A version of a flipperzero that has the same capabilities of Sub-GHz RF, IR, Wifi, and NFC/RFID

Dive into a world of innovation with our curated collection of hardware components straight from the electronics hub of Shenzhen, complemented by an array of parts supported by Seeed Studio. Our mission is to empower makers, developers, and hardware enthusiasts with a diverse repository that streamlines innovation and accelerates development.

The Seeed Fusion Open Parts Libraries (OPL) and the associated component libraries are provided and maintained by the Seeed Studio Fusion team and the wider community for the turnkey Seeed Fusion PCB Assembly (PCBA) Service.

Wio-SX1262 for ESP32S3, from the project README
From the project README

Main components on the Wio-SX1262 for ESP32S3

Wio-SX1262

Wio-SX1262 for ESP32S3 bill of materials (BOM)

15 components, 10 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
Wio-SX1262
SenseCAP
U1
2
Header 1x7 2.54mm
J1, J2
1
BTB SCOKET P0.40
30pin
LXWCONN E
J3
1
TS-1185E
百斯特
K1
1
Test Point
TP1
1
19-217/G7C-AN1P2/3T
Green
Everlight
D1
1
CC0402KRX7R7BB104
100nF
YAGEO
C1
2
RC0402JR-0710KL
10K
YAGEO
R1, R3
1
RC0402FR-07330RL
330R
YAGEO
R2
4
RC0201FR-0745RL
47R
YAGEO
R4, R5, R6, R7

Wio-SX1262 for ESP32S3 design files

The KiCad project lives in the jadenvv/NULL repository on GitHub; these links point at the commit this page was built from.

Wio-SX1262 for ESP32S3: common questions

How big is the Wio-SX1262 for ESP32S3 PCB?

The Wio-SX1262 for ESP32S3 measures 17.8 × 21.4 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Wio-SX1262 for ESP32S3?

15 components, from 10 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Wio-SX1262 for ESP32S3 design files?

From the jadenvv/NULL repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Wio-SX1262 for ESP32S3 design in my own project?

The repository has no license, so all rights stay with jadenvv. Use it as a reference, and ask the author before reusing the design.
