Db rev1

jemmec·legshark·kicad-files/db_rev1.kicad_pcb

Db rev1 PCB layout, top view — open source board by jemmec

About the Db rev1 PCB

Db rev1 is an open source PCB design by jemmec, published on GitHub under the MIT license. It is a 2-layer board measuring 22 × 25 mm, with 16 components from 13 distinct parts.

Other key parts include the TPD4E05U06DQAR and MCP1700T-3302E/TT. By type, the board carries 4 resistors, 2 ICs, 2 connectors, 2 diodes, 2 capacitors and 1 fuse.

It belongs with the keyboards designs in this gallery.

From the project

An open source 60% (15 by 5) ortholinear keyboard designed with both flexability and familiarity in mind.

An open source 60% (15 by 5) ortholinear keyboard designed with both flexability and familiarity in mind.

- Highly customizable 60% ortho layout - "Plateless" o-ring mounting - 3D printable case - UDB Support

The PCB supports many different layout options for the bottom row, embracing 1u keys but also with some left and right 1.5u modifier options.

The board also supports use of 2u keys in the usual TAB, LSHIFT, DELETE, and ENTER locations to maintain familiarity and speed with these often used modifiers.

Db rev1, from the project README
From the project README

Main components on the Db rev1

TPD4E05U06DQARMCP1700T-3302E/TT

Db rev1 bill of materials (BOM)

16 components, 13 distinct parts.

QtyPartRefs
1
TPD4E05U06DQAR
Texas Instruments
U1
1
MCP1700T-3302E/TT
Microchip
U2
1
TYPE-C-31-M-12
Koren Hroparts
J1
1
Conn_01x02
J2
1
SMD0805-050-16V
F1
1
LegSharkLogo
H1
1
53261-0471
T1
1
ESD5Z5V0
MDD
D1
1
B5819W-SL
Changjiang Electronics Tech
D2
1
GZ2012D601TF
FB1
2
0603B105K500NT
1uF
Guangdong Fenghua Advanced Tech
C3, C5
2
5.1k
R1, R2
2
100k
YAGEO
R3, R4

Db rev1 design files

The KiCad project lives in the jemmec/legshark repository on GitHub; these links point at the commit this page was built from.

Db rev1: common questions

How big is the Db rev1 PCB?

The Db rev1 measures 22 × 25 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Db rev1?

16 components, from 13 distinct parts. The full bill of materials is listed on this page.

Where can I download the Db rev1 design files?

From the jemmec/legshark repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Db rev1 design in my own project?

Yes, under the terms of its MIT license, which jemmec chose for the repository.
