WatchBlocksTop
About the WatchBlocksTop PCB
WatchBlocksTop is an open source PCB design by Leeianiop, published on GitHub. It is a 4-layer board measuring 52 × 62.5 mm, with 2 components from 1 distinct parts.
It belongs with the audio and power & battery designs in this gallery.
From the project
The New Fashion is Customizable
WatchBlocksTop bill of materials (BOM)
2 components, 1 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | Conn_01x07_Socket | PinSocket_1x07_P2.54mm_Vertical | ESP32S3XIAO10, ESP32S3XIAO12 |
WatchBlocksTop design files
The KiCad project lives in the Leeianiop/WatchBlocks repository on GitHub; these links point at the commit this page was built from.
WatchBlocksTop: common questions
How big is the WatchBlocksTop PCB?
The WatchBlocksTop measures 52 × 62.5 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the WatchBlocksTop?
2 components, from 1 distinct parts. The full bill of materials is listed on this page.
Where can I download the WatchBlocksTop design files?
From the Leeianiop/WatchBlocks repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the WatchBlocksTop design in my own project?
The repository has no license, so all rights stay with Leeianiop. Use it as a reference, and ask the author before reusing the design.
