PCB2 PCB layout, top view — open source board by lukasloetkolben

About the PCB2 PCB

PCB2 is an open source PCB design by lukasloetkolben, published on GitHub under the MIT license. It is a 4-layer board measuring 28.3 × 54 mm, with 15 components from 12 distinct parts.

Other key parts include the DG419LEUA. By type, the board carries 6 connectors, 4 resistors, 3 diodes and 2 ICs.

From the project

If you have any questions contact me on Discord: elkoled

PCB2, from the project README
From the project README

Main components on the PCB2

DG419LEUA

PCB2 bill of materials (BOM)

15 components, 12 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
DG419LEUA
U1, U2
1
to_EPS_1
J1
1
to_EPS_2
J2
1
to_ESP_3
J3
1
USB_C_Receptacle
J7
1
B2B_1
J8
1
B2B_2
J9
2
BAS40TW-AU
D1, D2
1
SMF16A
D3
2
1206W4F1200T5E
120R
UNI-ROYAL(厚声)
R1, R3
1
0603WAF1000T5E
120R
UNI-ROYAL(厚声)
R2
1
120R
R4

PCB2 design files

The KiCad project lives in the lukasloetkolben/OpenpilotHardware repository on GitHub; these links point at the commit this page was built from.

PCB2: common questions

How big is the PCB2 PCB?

The PCB2 measures 28.3 × 54 mm, has 4 copper layers and is 1.69 mm thick.

How many components are on the PCB2?

15 components, from 12 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the PCB2 design files?

From the lukasloetkolben/OpenpilotHardware repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the PCB2 design in my own project?

Yes, under the terms of its MIT license, which lukasloetkolben chose for the repository.
