About the KBoard PCB

KBoard is an open source RP2040/RP2350 PCB design by mihranrazaa, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 395.5 × 135 mm, with 180 components from 12 distinct parts.

Its main chip is the Raspberry_Pi_Pico, from the RP2040/RP2350 family. By type, the board carries 92 switches, 87 diodes and 1 IC.

It belongs with the keyboards designs in this gallery.

From the project

a 75%% keyboard PCB design.

The files for the PCB and Schematics are available in the Kicad folder and gerber files are added in the Production folder..

The files for the case and plate are available in the CAD folder and in the Production folder..

KBoard, from the project README — From the project README

Main components on the KBoard

Raspberry_Pi_Pico

KBoard bill of materials (BOM)

180 components, 12 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
1	Raspberry_Pi_Pico	Raspberry_Pi_Pico	U1
72	Keyswitch	MX_PCB_1.00u	S1, S2, S3, S4, S5, S6, S7, S8 +64
1	Keyswitch	MX_PCB_2.00u	S30
2	Keyswitch	MX_PCB_1.50u	S34, S47
1	Keyswitch	MX_PCB_1.75u	S51
2	Keyswitch	MX_PCB_2.25u	S63, S64
1	Keyswitch	MX_PCB_2.75u	S75
7	Keyswitch	MX_PCB_1.25u	S77, S78, S79, S81, S82, S83, S84
1	Keyswitch	MX_PCB_6.25u	S80
1	MX_stab	STAB_MX_P_6.25u	S88
4	MX_stab	STAB_MX_P_2u	S89, S90, S91, S92
87	1N4148	D_DO-35_SOD27_P7.62mm_Horizontal	D1, D2, D3, D4, D5, D6, D7, D8 +79

KBoard design files

The KiCad project lives in the mihranrazaa/KBoard repository on GitHub; these links point at the commit this page was built from.

KBoard: common questions

What microcontroller does the KBoard use?

The KBoard is built around the Raspberry_Pi_Pico, from the RP2040/RP2350 family.

How big is the KBoard PCB?

The KBoard measures 395.5 × 135 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the KBoard?

180 components, from 12 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the KBoard design files?

From the mihranrazaa/KBoard repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the KBoard design in my own project?

Yes, under the terms of its GPL-3.0 license, which mihranrazaa chose for the repository.

Can I test firmware for the KBoard without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
