SH101 IO PCB layout, top view — open source board by minisystem

About the SH101 IO PCB

SH101 IO is an open source PCB design by minisystem, published on GitHub. It is a 2-layer board measuring 33 × 36 mm, with 3 components from 3 distinct parts.

It belongs with the audio designs in this gallery.

From the project

MOD GRIP REPLACEMENT BOARD FOR SH-101 TRS MIDI IO

The project was designed in Kicad 6.0. The BOM and pos files for PCBA of the modulation grip spacer PCB with SMT spacers have been formatted for the JLC PCBA service.

You'll also need a Type A 3.5 MM TRS MIDI cable and a 2.5 MM TRS MIDI cable if you want access to MIDI OUT data. The 2.5 MM TRS to MIDI cable isn't as widely availabe, but is used by a lot of IK Multimedia iRig series products.

SH101 IO, from the project README
From the project README

SH101 IO bill of materials (BOM)

3 components, 3 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
AudioJack3
J1
1
AudioJack3
J2
1
Conn_01x05_Male
J3

SH101 IO design files

The KiCad project lives in the minisystem/SH101-MIDI-IO repository on GitHub; these links point at the commit this page was built from.

SH101 IO: common questions

How big is the SH101 IO PCB?

The SH101 IO measures 33 × 36 mm, has 2 copper layers and is 1 mm thick.

How many components are on the SH101 IO?

3 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the SH101 IO design files?

From the minisystem/SH101-MIDI-IO repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the SH101 IO design in my own project?

The repository has no license, so all rights stay with minisystem. Use it as a reference, and ask the author before reusing the design.
