Film capacitors

owntech-foundation·micro-inverter·KiCAD_Files/film_capacitors.kicad_pcb

Film capacitors PCB layout, top view — open source board by owntech-foundation
Simulate this board

About the Film capacitors PCB

Film capacitors is an open source PCB design by owntech-foundation, published on GitHub under the CERN-OHL-S-2.0 license. It is a 2-layer board measuring 129 × 32 mm, with 7 components from 2 distinct parts.

By type, the board carries 4 connectors and 3 capacitors.

It belongs with the power & battery designs in this gallery.

From the project

A repository to do collective work on an open source micro-inverter.

- Having the first open source PV micro-inverter - Finally a design easy to repair that is no longer a black box - Redeem your data sovereignty, you will no longer depend on a proprietary cloud to follow your solar production and consumption.

- This project is propulsed by its community. - The collective work generated is meant to remain open. - Design files are made with open source software - Namely kiCAD. - Mechanical interfaces and components are modeled using FreeCAD. - Simulation files use ngSpice.

Film capacitors, from the project README
From the project README

Film capacitors bill of materials (BOM)

7 components, 2 distinct parts.

QtyPartRefs
4
Conn_01x04
J101, J102, J103, J104
3
40uF
C1, C2, C3

Film capacitors design files

The KiCad project lives in the owntech-foundation/micro-inverter repository on GitHub; these links point at the commit this page was built from.

Film capacitors: common questions

How big is the Film capacitors PCB?

The Film capacitors measures 129 × 32 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Film capacitors?

7 components, from 2 distinct parts. The full bill of materials is listed on this page.

Where can I download the Film capacitors design files?

From the owntech-foundation/micro-inverter repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Film capacitors design in my own project?

Yes, under the terms of its CERN-OHL-S-2.0 license, which owntech-foundation chose for the repository.
