Thin-Pod rev0.1
About the Thin-Pod rev0.1 PCB
Thin-Pod rev0.1 is an open source PCB design by Pealie, published on GitHub under the CC-BY-4.0 license. It is a 2-layer board measuring 80 × 80 mm, with 21 components from 21 distinct parts.
Other key parts include the ZVP2106A, S7V8F3 regulator and DWM3001CDK. By type, the board carries 7 test points, 4 ICs, 4 resistors, 3 capacitors, 1 connector and 1 fuse.
It belongs with the sensors, test & measurement and dev boards & breakouts designs in this gallery.
From the project
OSHWA-certified open-hardware vibration sensing node for measurement integrity, machine-condition monitoring and Gateway-side telemetry experiments.
Thin-Pod rev 0.1 is a compact analogue vibration-sensing carrier board intended for experimental condition-monitoring work on motors, pumps, fans, gearboxes and similar rotating machinery. The board supports an ADXL1005-based analogue accelerometer signal path and provides protected power entry, a regulated and switched sensor supply, signal conditioning, accessible test points and a mating interface for a commercially supplied Qorvo DWM3001-CDK development board.
Main components on the Thin-Pod rev0.1
Thin-Pod rev0.1 bill of materials (BOM)
21 components, 21 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | ~ | AnalogDevices_EVAL-ADXL100xZ_20p35mm | U2 |
| 1 | ZVP2106A ~ Diodes Incorporated | PFET_ZVP2106A_GSD_THT | U3 |
| 1 | S7V8F3 regulator | Pololu_S7V8F3_S7V8x_Module | U4 |
| 1 | DWM3001CDK DWM3001C-CDK Qorvo | ThinPod_DWM3001CDK_Mating_Interface_revA_KiCad10 | U5 |
| 1 | ~ | JST_PH_S2B-PH-K_1x02_P2.00mm_Horizontal | J1 |
| 1 | Fuse 1A | Fuseholder_Littelfuse_445_030_series_5x20mm | F1 |
| 1 | RAW_IN | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP1 |
| 1 | RAW_FUSED | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP2 |
| 1 | RAW_PROT | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP3 |
| 1 | 3V3+ | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP4 |
| 1 | GND | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP5 |
| 1 | SENSOR_SIGNAL_RAW | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP6 |
| 1 | SENSOR_SIGNAL_FILTERED | TestPoint_THTPad_D1.5mm_Drill0.7mm | TP7 |
| 1 | 1N5817 Vishay or equivalent | D_DO-41_SOD81_P10.16mm_Horizontal | D1 |
| 1 | 680pF | C_Disc_D3.0mm_W1.6mm_P2.50mm | C1 |
| 1 | 100nF | C_Disc_D3.0mm_W1.6mm_P2.50mm | C2 |
| 1 | 10uF | C_Disc_D5.0mm_W2.5mm_P5.00mm | C3 |
| 1 | 8K | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R1 |
| 1 | 100K | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R2 |
| 1 | 1K | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R3 |
Show 1 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 1M | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R4 |
Thin-Pod rev0.1 design files
The KiCad project lives in the Pealie/Thin-Pod-rev0.1 repository on GitHub; these links point at the commit this page was built from.
Thin-Pod rev0.1: common questions
How big is the Thin-Pod rev0.1 PCB?
The Thin-Pod rev0.1 measures 80 × 80 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Thin-Pod rev0.1?
21 components, from 21 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Thin-Pod rev0.1 design files?
From the Pealie/Thin-Pod-rev0.1 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Thin-Pod rev0.1 design in my own project?
Yes, under the terms of its CC-BY-4.0 license, which Pealie chose for the repository.
