Fsae pihat usbmod

picafe·fsae-daq-hat·fsae-pihat-usbmod/fsae-pihat-usbmod.kicad_pcb

Fsae pihat usbmod PCB layout, top view — open source Raspberry Pi board by picafe

About the Fsae pihat usbmod PCB

Fsae pihat usbmod is an open source Raspberry Pi PCB design by picafe, published on GitHub. It is a 2-layer board measuring 41.9 × 18.2 mm, with 3 components from 3 distinct parts.

Its main chip is the RASPBERRY_PI_4, from the Raspberry Pi family. Other key parts include the TPS5430DDAR. By type, the board carries 2 connectors and 1 IC.

It belongs with the dev boards & breakouts designs in this gallery.

From the project

A Raspberry Pi 4B hat to help power analytics in a FSAE car ⚡

This PCB is the external 20 V USB-C PD → 24 V boost module used with the main Pi HAT. It pairs a PDC004 V2 USB-C PD trigger (fixed 20 V) with an MT3608 boost module to generate 24 V for PoE injection on the base station antenna and for convenient bench power during testing. This is a companion PCB to the main Pi HAT.

Since the current here would be pretty low, I decided to use a MT3608 and PDC004 PD module (I already have one, and the design seems pretty good; really big power plane on bottom) on a separate PCB instead of putting a boost converter on the HAT.

Fsae pihat usbmod, from the project README
From the project README

Main components on the Fsae pihat usbmod

TPS5430DDAR

Fsae pihat usbmod bill of materials (BOM)

3 components, 3 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
TPS5430DDAR
MT3608 Boost
U1
1
RASPBERRY_PI_4
Conn_01x03_Socket
J1
1
1-2834011-4
HUSB238 Module
J2

Fsae pihat usbmod design files

The KiCad project lives in the picafe/fsae-daq-hat repository on GitHub; these links point at the commit this page was built from.

Fsae pihat usbmod: common questions

What microcontroller does the Fsae pihat usbmod use?

The Fsae pihat usbmod is built around the RASPBERRY_PI_4, from the Raspberry Pi family.

How big is the Fsae pihat usbmod PCB?

The Fsae pihat usbmod measures 41.9 × 18.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Fsae pihat usbmod?

3 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Fsae pihat usbmod design files?

From the picafe/fsae-daq-hat repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Fsae pihat usbmod design in my own project?

The repository has no license, so all rights stay with picafe. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Fsae pihat usbmod without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug Raspberry Pi firmware against it before you order a PCB.
