Servocontrollerproject

pioneers·PiElectrical·Boards/servocontrollerproject/servocontrollerproject.kicad_pcb

Servocontrollerproject PCB layout, top view — open source board by pioneers

About the Servocontrollerproject PCB

Servocontrollerproject is an open source PCB design by pioneers, published on GitHub. It is a 2-layer board measuring 40.3 × 52.4 mm, with 5 components from 4 distinct parts.

Other key parts include the C1849534. By type, the board carries 1 IC, 1 connector and 1 capacitor.

From the project

PiElectrical Work and Documentation

This is the working repo for PiElectrical teams

1. ToDo 2. Repo Structure 3. Setup 4. Work Flow 5. How to Create a Gerber 6. Docu Packets 7. FAQ 8. Useful Links 9. Standards

Boards: Contains all necessary information about each board, including KiCad (and old Eagle) files, arduino test files, and board specific documentation.

Bootloaders: Contains the files necessary to burn the bootloader for boards identifying as Leonardo (Atmega32u4).

Servocontrollerproject, from the project README
From the project README

Main components on the Servocontrollerproject

C1849534

Servocontrollerproject bill of materials (BOM)

5 components, 4 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
C1849534
ProMicro
U1
1
USB_A
J3
2
B3B-XH-A(LF)(SN)
~
JST Sales America Inc.
Servo0, Servo1
1
C2932475
1000u
C1

Servocontrollerproject design files

The KiCad project lives in the pioneers/PiElectrical repository on GitHub; these links point at the commit this page was built from.

Servocontrollerproject: common questions

How big is the Servocontrollerproject PCB?

The Servocontrollerproject measures 40.3 × 52.4 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Servocontrollerproject?

5 components, from 4 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Servocontrollerproject design files?

From the pioneers/PiElectrical repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Servocontrollerproject design in my own project?

The repository has no license, so all rights stay with pioneers. Use it as a reference, and ask the author before reusing the design.
