Micro mouse v3.1

prashantbhandary·MicroMouse-LineMaze·ArduinoNano/micro_mouse_v3_files/micro_mouse_v3.1-PCB/micro_mouse_v3.1-PCB.kicad_pcb

Micro mouse v3.1 PCB layout, top view — open source AVR/Arduino board by prashantbhandary
Simulate this board

About the Micro mouse v3.1 PCB

Micro mouse v3.1 is an open source AVR/Arduino PCB design by prashantbhandary, published on GitHub. It is a 2-layer board measuring 74 × 60.3 mm, with 18 components from 12 distinct parts.

Its main chip is the Arduino_Nano_v3.x, from the AVR/Arduino family. Other key parts include the L293D and LM7805_TO220. By type, the board carries 7 connectors, 4 resistors, 3 switches, 2 ICs, 1 module and 1 diode.

It belongs with the robotics & motion and sensors designs in this gallery.

From the project

Meshmerize MicroMouse Project

Our MicroMouse has proven its excellence in prestigious robotics competitions:

- 🥇 1st Place - Locus, Pulchowk Campus - 🥈 2nd Place - Delta 5.0, Dharan IOE - 🏅 5th Place - Techfest, IIT Bombay 2024

- 🎯 Project Overview - ✨ Key Features - 🔧 Hardware Versions - 💻 Software Architecture - 🚀 Getting Started - 📁 Repository Structure - 🛠️ Installation & Setup - 🎮 Usage Instructions - 🧠 Algorithms & Control Systems - 📷 Project Gallery - 🤝 Contributing - 📄 License

Micro mouse v3.1, from the project README
From the project README

Main components on the Micro mouse v3.1

L293DLM7805_TO220Arduino_Nano_v3.x

Micro mouse v3.1 bill of materials (BOM)

18 components, 12 distinct parts.

QtyPartRefs
1
L293D
U1
1
LM7805_TO220
U3
1
Arduino_Nano_v3.x
A1
2
B2B-XH-A (LF)(SN)
CN1, CN2
1
Conn_01x11_Pin
J1
2
Conn_01x01_Pin
J2, J3
1
~
P1
1
~
cn3
3
SW_Push
SW1, SW2, SW3
1
LED
D1
1
R
R1
3
10K
R2, R3, R4

Micro mouse v3.1 design files

The KiCad project lives in the prashantbhandary/MicroMouse-LineMaze repository on GitHub; these links point at the commit this page was built from.

Micro mouse v3.1: common questions

What microcontroller does the Micro mouse v3.1 use?

The Micro mouse v3.1 is built around the Arduino_Nano_v3.x, from the AVR/Arduino family.

How big is the Micro mouse v3.1 PCB?

The Micro mouse v3.1 measures 74 × 60.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Micro mouse v3.1?

18 components, from 12 distinct parts. The full bill of materials is listed on this page.

Where can I download the Micro mouse v3.1 design files?

From the prashantbhandary/MicroMouse-LineMaze repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Micro mouse v3.1 design in my own project?

The repository has no license, so all rights stay with prashantbhandary. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Micro mouse v3.1 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
