LED Board

rassweiler·pi-networked-counter·Schematics/LED_Board/LED_Board.kicad_pcb

LED Board layout, top view — open source board by rassweiler

About the LED Board

LED Board is an open source PCB design by rassweiler, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 55 × 34 mm, with 10 components from 3 distinct parts.

Other key parts include the AQY210EH. By type, the board carries 5 resistors, 4 ICs and 1 connector.

It belongs with the displays & leds, power & battery and dev boards & breakouts designs in this gallery.

From the project

3d printed counter using Pi5, python, pyqt6, and sqlite that can export to folders or sharepoint

- Setup keyring for sharepoint integration Run seahorse and make sure there is a default keystore

- Copy the desktop file to autostart the app:

Then restart the system to get the app in the menu under other, then right click the app and select add to taskbar

- Add to the .settup.toml file your sharepoint access details:

- run the gettoken.sh` script once to initialise your sharepoint token, it should provide a link and a key to login using a browser.

LED Board, from the project README
From the project README

Main components on the LED Board

AQY210EH

LED Board bill of materials (BOM)

10 components, 3 distinct parts.

QtyPartRefs
4
AQY210EH
U1, U2, U3, U4
1
Conn_01x12_Pin
J9
5
220
R1, R2, R3, R4, R5

LED Board design files

The KiCad project lives in the rassweiler/pi-networked-counter repository on GitHub; these links point at the commit this page was built from.

LED Board: common questions

How big is the LED Board?

The LED Board measures 55 × 34 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the LED Board?

10 components, from 3 distinct parts. The full bill of materials is listed on this page.

Where can I download the LED Board design files?

From the rassweiler/pi-networked-counter repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the LED Board design in my own project?

Yes, under the terms of its GPL-3.0 license, which rassweiler chose for the repository.
