SKYWAY-96

RivasMario·SKYWAY-96·KiCAD Source Files/rivasmario 96% Hotswap Rp2040.kicad_pcb

SKYWAY-96 PCB layout, top view — open source RP2040/RP2350 board by RivasMario

About the SKYWAY-96 PCB

SKYWAY-96 is an open source RP2040/RP2350 PCB design by RivasMario, published on GitHub. It is a 2-layer board measuring 362 × 114.3 mm, with 281 components from 21 distinct parts.

Its main chip is the C2040, from the RP2040/RP2350 family. Other key parts include the C6186 and C97521. By type, the board carries 99 diodes, 44 capacitors, 20 LEDs, 11 resistors, 3 ICs and 1 crystal.

It belongs with the keyboards designs in this gallery.

From the project

Mechanical Keyboard PCB and Plate powered by QMK for a 96% board

A 96% mechanical keyboard PCB built around the RP2040, with Kailh hotswap sockets and underglow RGB. Designed for JLCPCB assembly and Melody96-compatible cases.

- Specs - Photos & Renders - Layout - Repository Layout - Firmware: Setup & Flashing - Troubleshooting - Credits

All renders and 2D images (keycaps, stabilizers, layouts, alternate angles) live in Photos/.

SKYWAY-96, from the project README
From the project README

Main components on the SKYWAY-96

C6186C97521C2040

SKYWAY-96 bill of materials (BOM)

281 components, 21 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
C6186
AMS1117-3.3
U1
1
C97521
W25Q128JVS
U3
1
C2040
RP2040
U4
1
C9002
12MHz
Y1
1
C165948
USB_C_Receptacle_USB2.0
J4
2
C92584
SW_SPST
Boot1, RST1
1
C2827688
PRTR5V0U2X
ESD1
99
C41430893
MX-NoLED
MX1, MX2, MX3, MX4, MX5, MX6, MX7, MX8 +91
18
C2761795
WS2812B
LED1, LED2, LED3, LED4, LED5, LED6, LED7, LED8 +10
2
C131223
LED
Pwr1, Test1
99
C81598
1N4148W
D1, D2, D3, D4, D5, D6, D7, D8 +91
7
C440198
10uf
C1, C3, C10, C17, C27, C29, C31
4
C126469
100nf
C2, C4, C30, C32
29
C77020
100nf
C5, C6, C7, C8, C9, C11, C12, C13 +21
2
C1518208
1uf
C33, C43
2
C1555
22pf
C44, C45
3
C25117
470
R1, R2, R17
2
C25905
5.1K
R18, R19
2
C11702
1k
R20, R27
2
C25744
10k
R21, R22
Show 1 more
QtyPartRefs
2
C25092
22
R25, R26

SKYWAY-96 design files

The KiCad project lives in the RivasMario/SKYWAY-96 repository on GitHub; these links point at the commit this page was built from.

SKYWAY-96: common questions

What microcontroller does the SKYWAY-96 use?

The SKYWAY-96 is built around the C2040, from the RP2040/RP2350 family.

How big is the SKYWAY-96 PCB?

The SKYWAY-96 measures 362 × 114.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the SKYWAY-96?

281 components, from 21 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the SKYWAY-96 design files?

From the RivasMario/SKYWAY-96 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the SKYWAY-96 design in my own project?

The repository has no license, so all rights stay with RivasMario. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the SKYWAY-96 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
