Keyboard PCB layout, top view — open source RP2040/RP2350 board by rosikur

About the Keyboard PCB

Keyboard is an open source RP2040/RP2350 PCB design by rosikur, published on GitHub. It is a 2-layer board measuring 388.6 × 139.7 mm, with 166 components from 6 distinct parts.

Its main chip is the RaspberryPi_Pico, from the RP2040/RP2350 family. By type, the board carries 85 switches, 80 diodes and 1 module.

It belongs with the keyboards designs in this gallery.

From the project

I dont know what to call it so lets call it "keeb" because thats the name of the guide

I dont know what to call it so lets call it "keeb" because thats the name of the guide

This was my first keyboard , apart from my macropad ,the keyboard took 3 times , more on that on my Journal

In the meantime while it ships you start printing the Case,if your Printer is too small , half it or you can order it off print legion

Once everything is ready , you grab some solder and an iron , i recommend leaded solder makes it easier,firstly take your pi pico and add the male pins,then put it trough and solder everything and snap off its legs outside

Keyboard, from the project README
From the project README

Main components on the Keyboard

RaspberryPi_Pico

Keyboard bill of materials (BOM)

166 components, 6 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
RaspberryPi_Pico
A1
1
MX_stab
S1
3
MX_stab
S2, S3, S4
80
SW_Push
SW1, SW2, SW3, SW4, SW5, SW6, SW7, SW8 +72
1
RotaryEncoder_Switch
SW42
80
1N4148
D1, D2, D3, D4, D5, D6, D7, D8 +72

Keyboard design files

The KiCad project lives in the rosikur/keyboard repository on GitHub; these links point at the commit this page was built from.

Keyboard: common questions

What microcontroller does the Keyboard use?

The Keyboard is built around the RaspberryPi_Pico, from the RP2040/RP2350 family.

How big is the Keyboard PCB?

The Keyboard measures 388.6 × 139.7 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Keyboard?

166 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Keyboard design files?

From the rosikur/keyboard repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Keyboard design in my own project?

The repository has no license, so all rights stay with rosikur. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Keyboard without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
