Bykeeb

sadekbaroudi·bykeeb·pcb/mx-choc-ks27/bykeeb.kicad_pcb

Bykeeb PCB layout, top view — open source Nordic nRF board by sadekbaroudi
Simulate this board

About the Bykeeb PCB

Bykeeb is an open source Nordic nRF PCB design by sadekbaroudi, published on GitHub. It is a 2-layer board measuring 246.5 × 92.8 mm, with 84 components from 7 distinct parts.

Its main chip is the XIAO-BLE, from the Nordic nRF family. By type, the board carries 38 switches, 36 diodes, 2 ICs, 2 modules and 2 connectors.

It belongs with the keyboards and iot & wireless designs in this gallery.

From the project

This is a 36 key wireless keyboard using a seeed xiao nrf52840 controller, supporting choc, gateron low profile, and MX switches.

This is a 36 key wireless keyboard using a seeed xiao nrf52840 controller, supporting choc, gateron low profile, and MX switches.

Firmware is done in ZMK, and can be found in the zmk-fingerpunch-keyboards github repository, specifically in the boards/shields/bykeeb directory.

Use the gerber.zip found in the pcb directory. If you are using jlcpcb, you can also use the bom.csv and positions.csv to do PCBA

Bykeeb, from the project README
From the project README

Bykeeb bill of materials (BOM)

84 components, 7 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
SW_Push
U1, U2
2
XIAO-BLE
M1, M2
2
CONN_01X03_FEMALE
Conn_01x03_Female
J1, J2
4
Breakaway Tabs
H7, H8, H9, H10
36
SW_Push
SW1, SW2, SW3, SW4, SW5, SW6, SW7, SW8 +28
2
C431540
SW_DPDT
SW37, SW38
36
1N4148W
D1, D2, D3, D4, D5, D6, D7, D8 +28

Bykeeb design files

The KiCad project lives in the sadekbaroudi/bykeeb repository on GitHub; these links point at the commit this page was built from.

Bykeeb: common questions

What microcontroller does the Bykeeb use?

The Bykeeb is built around the XIAO-BLE, from the Nordic nRF family.

How big is the Bykeeb PCB?

The Bykeeb measures 246.5 × 92.8 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Bykeeb?

84 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Bykeeb design files?

From the sadekbaroudi/bykeeb repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Bykeeb design in my own project?

The repository has no license, so all rights stay with sadekbaroudi. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Bykeeb without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug Nordic nRF firmware against it before you order a PCB.
