Baud Generator

tangent3D·Z-FIGHTER·hardware/peripherals/baud_generator/kicad/Baud_Generator.kicad_pcb

Baud Generator PCB layout, top view — open source board by tangent3D

About the Baud Generator PCB

Baud Generator is an open source PCB design by tangent3D, published on GitHub under the MIT license. It is a 2-layer board measuring 16.5 × 41 mm, with 6 components from 6 distinct parts.

Other key parts include the 4024. By type, the board carries 2 connectors, 1 IC, 1 crystal and 1 capacitor.

It belongs with the retro computing designs in this gallery.

From the project

Homebrew Z80 hobby computer

Baud Generator, from the project README
From the project README

Main components on the Baud Generator

4024

Baud Generator bill of materials (BOM)

6 components, 6 distinct parts.

QtyPartRefs
1
4024
U1
1
2.4576 MHz
X1
1
Conn_02x04_Odd_Even
J1
1
Conn_02x07_Odd_Even
J2
1
0.1uF
0.1uF
1
0.1uF
C2

Baud Generator design files

The KiCad project lives in the tangent3D/Z-FIGHTER repository on GitHub; these links point at the commit this page was built from.

Baud Generator: common questions

How big is the Baud Generator PCB?

The Baud Generator measures 16.5 × 41 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Baud Generator?

6 components, from 6 distinct parts. The full bill of materials is listed on this page.

Where can I download the Baud Generator design files?

From the tangent3D/Z-FIGHTER repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Baud Generator design in my own project?

Yes, under the terms of its MIT license, which tangent3D chose for the repository.
